300/500V Puro-Jz/Puro-Oz Enhanced Oil Resistance PUR Rubber Sheath Control Cable
300/500V Puro-Jz/Puro-Oz Enhanced Oil Resistance PUR Rubber Sheath Control Cable image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
PURö-JZ / PURö-OZ enhanced oil resistance control and connection cable
Connection and control cable with a high-grade oil-resistant PVC core insulation. Due to its resistance to mineral oils, notably against coolant emulsions, it is suited for use in particularly critical locations in machine, tool and plant construction, rolling mills and steel works. Suitable for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, as well as outdoors.
Properties:
1.Resistant to: oil, UV radiation, ozone, oxygen, weathering effects, hydrolysis, microbes, coolants, hydraulic fluids,
acids, alkalis, greases, seawater and wastewater
2.Highly abrasion-resistant, notch-resistant, tear-resistant, cut-resistant,wear-resistant, low adhesion for outdoor use
3.The materials used during manufacturing are cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquers
* Copper wire bare, finely stranded acc. to DIN VDE 0295 Class 5 / IEC 60228 Class 5
* Core insulation: oil-resistant PVC in alignment with DIN VDE 0207- 363-3 / DIN EN 50363-3 (compound type TI2), with improved gliding behaviour
* Core identification acc. to DIN VDE 0293-334, black cores with consecutive labeling in white digits
* Protective conductor: starting with 3 cores,
G = with protective conductor GN-YE, in the outer layer,
x = without protective conductor (OZ)
* Cores stranded in layers with optimal lay lengths
* Outer sheath: Special grade of full polyurethane acc. to
DIN VDE 0207-363-10-2 / DIN EN 50363-10-2 (compound type TMPU)
* Sheath colour: grey (RAL 7001)
* Length marking: in metres
Specification:
PUR control and connection cable in alignment with DIN VDE 0285-525-1 / DIN EN 50525-1
Temperature range
flexible -20°C to +80°C
fixed -40°C to +80°C
Nominal voltage
AC U0/U 300/500 V
Test voltage core/core 4000 V
Breakdown voltage 8000 V
Minimum bending radius
flexible 7.5x Outer-Ø
fixed 4x Outer-Ø
Cable Parameter:
|
No. cores x cross-sec. mm2
|
AWG, approx.
|
Outer Omm, approx.
|
Cu factor per km
|
Weight kg/km, approx.
|
|
2×0.5
|
20
|
4.8
|
9.6
|
45.0
|
|
3G0.5
|
20
|
5.1
|
14.4
|
55.0
|
|
3×0.5
|
20
|
5.1
|
14.4
|
55.0
|
|
4G0.5
|
20
|
5.5
|
19.0
|
65.0
|
|
4×0.5
|
20
|
5.5
|
19.0
|
65.0
|
|
5G0.5
|
20
|
6.2
|
24.0
|
75.0
|
|
5×0.5
|
20
|
6.2
|
24.0
|
75.0
|
|
7G0.5
|
20
|
6.7
|
33.6
|
90.0
|
|
7×0.5
|
20
|
6.7
|
33.6
|
90.0
|
|
10G0.5
|
20
|
8.6
|
48.0
|
120.0
|
|
12G0.5
|
20
|
8.9
|
58.0
|
135.0
|
|
18G0.5
|
20
|
10.7
|
86.0
|
205.0
|
|
25 G0.5
|
20
|
12.4
|
120.0
|
270.0
|
|
34G0.5
|
20
|
14.3
|
163.0
|
380.0
|
|
42 G0.5
|
20
|
15.8
|
202.0
|
415.0
|
|
2×0.75
|
19
|
5.3
|
14.4
|
44.0
|
|
3G0.75
|
19
|
5.6
|
21.6
|
53.0
|
|
3×0.75
|
19
|
5.6
|
21.6
|
53.0
|
|
4G0.75
|
19
|
6.3
|
29.0
|
64.0
|
|
4×0.75
|
19
|
6.3
|
29.0
|
64.0
|
|
5G0.75
|
19
|
6.9
|
36.0
|
76.0
|
|
5×0.75
|
19
|
6.9
|
36.0
|
76.0
|
|
7G0.75
|
19
|
7.5
|
50.0
|
96.0
|
|
7×0.75
|
19
|
7.5
|
50.0
|
96.0
|
|
10G0.75
|
19
|
9.6
|
72.0
|
140.0
|
|
12G0.75
|
19
|
9.9
|
86.0
|
170.0
|
|
18G0.75
|
19
|
12.2
|
130.0
|
260.0
|
|
25G0.75
|
19
|
14.1
|
180.0
|
282.0
|
|
34G0.75
|
19
|
16.5
|
245.0
|
475.0
|
|
42G0.75
|
19
|
18.1
|
302.0
|
600.0
|
|
2×1
|
18
|
5.6
|
19.0
|
53.0
|
|
3G1
|
18
|
5.9
|
29.0
|
63.0
|
|
3×1
|
18
|
5.9
|
29.0
|
63.0
|
|
4G1
|
18
|
6.7
|
38.0
|
75.0
|
|
4×1
|
18
|
6.7
|
38.0
|
75.0
|
|
5G1
|
18
|
7.3
|
48.0
|
89.0
|
1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.
2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.
3.What does your company do regarding quality control?
1) all raw materials we selected are the highest quality.
2) professional and skillful workers care every details in handling the producing.
3) quality control department is specially responsible for quality checking in each process.
4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.
5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.
We are China 300/500V Puro-Jz/Puro-Oz Enhanced Oil Resistance PUR Rubber Sheath Control Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
