300/500V Opvc-Oz Opvc-Jz Opvc-Oz-Cy Opvc-Jz-Cy Ysly Yy Power Control Connecting Cable

300/500V Opvc-Oz Opvc-Jz Opvc-Oz-Cy Opvc-Jz-Cy Ysly Yy Power Control Connecting Cable image

Get Latest Price Request a quote

Product Details

Model NO.

OPVC-OZ

Application

Heating, Industrial

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Certification

VDE, EU/IEC

Brand

Huadong

Rated Voltage

300/500V

Core

4 5 7 8 12 or Others

Temperature

-5 Deg to 70 Deg C

Sample

Available

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

300/500V OPVC-OZ OPVC-JZ OPVC-OZ-CY OPVC-JZ-CY YSLY YY power control connecting cable

Application:

To be used as power, control and connecting cable in electrical facilities for fixed laying and flexible applications without tensile stress and without defined cable routing. Suitable for use in dry, humid and wet rooms. Outdoor use only with UV-protection, no laying underground. Applicable also for YSLY or YY.

Specification:
Suitable as control cable   Yes
Conductor material   Copper
Conductor surface   Bare
Shape of conductor   Round
Conductor category   Class 5 = flexible
Protective conductor   Yes
Screen   Yes
Screen over stranding   Braiding
Reaction-to-fire according to EN 13501-6: Class   Dca
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles   d1
Reaction-to-fire according to EN 13501-6: Acidity   a3
Permitted cable outer temperature during assembling/handling   -5 / 70 °C
Permitted cable outer temperature after assembling without vibration   -40 / 80 °C
Max. conductor temperature   70 °C
Nominal voltage U0   300 V
Nominal voltage U   500 V

Construction	Gewicht (kg/km)	Outer diameter approx. (mm)	Aderkleuren
4 G 0,5 mm Grey	53	6.1	Yellow / Green – Black numbered
5 G 0,5 mm Grey	66	6.6	Yellow / Green – Black numbered
3 G 0,75 mmGrey	60	6.1	Yellow / Green – Black numbered
4 G 0,75 mm Grey	72	6.6	Yellow / Green – Black numbered
5 G 0,75 mmGrey	87	7.2	Yellow / Green – Black numbered
7 G 0,75 mmGrey	109	7.9	Yellow / Green – Black numbered
12 G 0,75 mm Grey	174	10.3	Yellow / Green – Black numbered
18 G 0,75 mm Grey	247	12.2	Yellow / Green – Black numbered
25 G 0,75 mm Grey	315	14.4	Yellow / Green – Black numbered
34 G 0,75 mm Grey	412	16	Yellow / Green – Black numbered
3 G 1 mm Grey	71	6.6	Yellow / Green – Black numbered
4 G 1 mm Grey	86	2	Yellow / Green – Black numbered
5 G 1 mm Grey	107	8	Yellow / Green – Black numbered
7 G 1 mm Grey	136	8.7	Yellow / Green – Black numbered
10 G 1 mm Grey	186	11	Yellow / Green – Black numbered
12 G 1 mm Grey	211	11.3	Yellow / Green – Black numbered
3 G 1,5 mm Grey	91	7	Yellow / Green – Black numbered
4 G 1,5 mm Grey	116	7.2	Yellow / Green – Black numbered
5 G 1,5 mm Grey	140	8.6	Yellow / Green – Black numbered
7 G 1,5 mm Grey	179	9.2	Yellow / Green – Black numbered
12 G 1,5 mm Grey	287	12.5	Yellow / Green – Black numbered
25 G 1,5 mm Grey	544	16.7	Yellow / Green – Black numbered
3 G 2,5 mm Grey	130	8.4	Yellow / Green – Black numbered
4 G 2,5 mm Grey	160	9.1	Yellow / Green – Black numbered
5 G 2,5 mm Grey	197	10.1	Yellow / Green – Black numbered
7 G 2,5 mm Grey	255	11	Yellow / Green – Black numbered
12 G 2,5 mm Grey	416	14.6	Yellow / Green – Black numbered
