300/500V Multi 2 3 4 Core Sihf High Temperature Resistant Silicone Rubber Wire Cable

300/500V Multi 2 3 4 Core Sihf High Temperature Resistant Silicone Rubber Wire Cable image

Get Latest Price Request a quote

Product Details

Model NO.

SIHF

Application

Heating, Electrical Appliances

Conductor Material

Tinned Copper

Sheath Material

Silicone Rubber

Insulation Material

Silicone Rubber

Material Shape

Round Wire

Certification

VDE

Brand

Huadong

Rated Voltage

300/500V

Cores

2-24 Cores

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

SIHF High Temperature Soft Tinned Copper Silicone Rubber Heating Cable Wire

Application:

In dry, humid and wet locations as well as in the open-air for low mechanical stress, particularly at high ambient temperatures.

Construction:

1…..fine-stranded tinned or bare copper

2…..core insulation of silicone (2GI1)

3…..outer sheath of silicone (2GM1), red-brown

Standards: DIN VDE 0207 part 20 DIN EN 60228 class 5 (construction) HD 308 S2 (core identification)

Technical data:

Nominal voltage Uo/U [V] 300 / 500 Volt

Test voltage [V]AC 2000

Temperature range in motion -60°C till 180°C

temporary resilient +250°C

Flammability standard EN 60332-1-2

Cable Parameters

Number of cores and nominal cross section mm²	Copper figure kg/km	Cond. construction (appr. value) mm	Overall diameter appr. mm	Weight appr. kg / km
2 x 0,75	14,40	24 x 0,21	6,4	63
3 x 0,75	21,60	24 x 0,21	6,8	76
4 x 0,75	28,80	24 x 0,21	7,8	101
5 x 0,75	36,00	24 x 0,21	8,5	120
7 x 0,75	50,40	24 x 0,21	9,2	148
2 x 1	19,20	32 x 0,21	6,6	71
3 x 1	28,80	32 x 0,21	7,4	93
4 x 1	38,40	32 x 0,21	8,1	113
5 x 1	48,00	32 x 0,21	8,8	136
7 x 1	67,20	32 x 0,21	9,5	169
2 x 1,5	28,80	30 x 0,26	7,6	97
3 x 1,5	43,20	30 x 0,26	8,0	117
4 x 1,5	57,60	30 x 0,26	8,8	145
5 x 1,5	72,00	30 x 0,26	9,6	175
7 x 1,5	100,80	30 x 0,26	10,9	220
12 x 1,5	172,80	30 x 0,26	14,6	413
16 x 1,5	230,40	30 x 0,26	16,2	520
24 x 1,5	345,60	30 x 0,26	20,4	811
2 x 2,5	48,00	50 x 0,26	9,2	146
3 x 2,5	72,00	50 x 0,26	9,7	179
4 x 2,5	96,00	50 x 0,26	10,6	222
5 x 2,5	120,00	50 x 0,26	11,6	268
7 x 2,5	168,00	50 x 0,26	12,6	339
12 x 2,5	288,00	50 x 0,26	17,1	609

Number of cores and nominal cross section mm²	Copper figure kg/km	Cond. construction (appr. value) mm	Overall diameter appr. mm	Weight appr. kg / km
2 x 4	76,80	50 x 0,31	10,8	210
3 x 4	115,20	50 x 0,31	11,5	261
4 x 4	153,60	50 x 0,31	13,2	346
5 x 4	192,00	50 x 0,31	14,3	418
7 x 4	268,80	50 x 0,31	15,6	530
4 x 6	230,40	84 x 0,31	15,6	497
5 x 6	288,00	84 x 0,31	17,6	631
4 x 10	384,00	80 x 0,41	19,1	778
4 x 16	614,40	128 x 0,41	23,4	1.197
4 x 25	960,00	200 x 0,41	28,6	1.827

1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?
1) All raw materials we selected are the highest quality.
2) Professional and skillful workers care every details in handling the producing.
3) Quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.

5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.
