300/500V Heat 180 H05ss-F Ewkf Europe-Wide Standardised Silicone Rubber Connection Cables for Steel Iron Works Plant

300/500V Heat 180 H05ss-F Ewkf Europe-Wide Standardised Silicone Rubber Connection Cables for Steel Iron Works Plant image

Get Latest Price Request a quote

Product Details

Model NO.

H05SS-F EWKF

Application

Heating, Electrical Appliances

Conductor Material

Tinned Copper

Sheath Material

Silicone Rubber

Insulation Material

Silicone Rubber

Material Shape

Round Wire

Certification

VDE

Brand

Huadong

Rated Voltage

300/500V

Cores

Single Core

Size

0.75mm to 6mm

Temperature Range

-55 to 180c

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

HEAT 180 H05SS-F EWKF

Europe-wide standardised silicone connection cables with increased mechanical performance

H05SS-F EWKF – silicone power cable according to type H05SS-F, for use in machines, plant construction and tool building, suitable for +180°C

Product Make-up

Fine-wire, tinned-copper conductor

Core insulation: based on EWKF silicone

Cores twisted together

Outer sheath: silicone-based EWKF, notch-resistant, black

Application range

Areas with high ambient temperatures and occasionally mechanical stress

Typical fields of application

– Steel, ceramic and iron works

– Bakery equipment and industrial furnaces

– Electric motor industry

Benefits

Harmonised use in Europe

Notch and tear-resistant silicone compounds reduce damage due to mechanical stress

For harsh environments, more durable than conventional H05SS-F standardised cables

Flexibility simplifies installation where space is limited

Possesses insulating properties after combustion due to remaining SiO2 ash on the conductor

Number of cores and mm2 per Conductor	Outer diameter [mm]	Copper index (kg/km)	Weight (kg/km)
2×0.75	6.4	14.4	54
3G0.75	7	21.6	67
4G0.75	7.6	28.8	87
5G0.75	8.5	36	105
2×1.0	6.8	19.2	63
3G1.0	7.2	28.8	81
4G1.0	7.9	38.4	98
5G1.0	8.8	48	121
2×1.5	8.4	28.8	84
3G 1.5	8.9	43.2	103
4G1.5	9.9	57.6	128
5G 1.5	10.9	72	154
2×2.5	9.8	48	141
3G2.5	10.4	72	158
4G2.5	11.6	96	195
5G2.5	12.9	120	241
3G4.0	12.31	115.2	239
4G4.0	13.71	153.6	312
3G6.0	14	172.8	345
4 G 6.0	15.6	230.4	451

1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?
1) All raw materials we selected are the highest quality.
2) Professional and skillful workers care every details in handling the producing.
3) Quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.

5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.
