300/500V Heat 180 GLS Steel Armoured Silicone Rubber Cables for Increased Mechanical Stress
300/500V Heat 180 GLS Steel Armoured Silicone Rubber Cables for Increased Mechanical Stress image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
180 GLS – steel-armoured silicone power and control cable for use in machines, plant construction and tool building for temperatures up to +180°C
Cable Parameters
| Number of cores and mm2 per conductor |
Outer diameter [mm] |
Copper index (kg/km) |
Weight (kg/km) |
| 2×0.75 | 7.6 | 14.4 | 84 |
| 3G0.75 | 8 | 21.6 | 96 |
| 4G0.75 | 8.8 | 28.8 | 118 |
| 5G0.75 | 9.7 | 36 | 145 |
| 6G0.75 | 10.4 | 43.2 | 167 |
| 7G0.75 | 10.4 | 50.4 | 171 |
| 2X1.0 | 7.8 | 19.2 | 92 |
| 3G1.0 | 8.2 | 28.8 | 106 |
| 4G1.0 | 9.1 | 38.4 | 132 |
| 5G1.0 | 10 | 48 | 161 |
| 7G1.0 | 10.7 | 67 | 205 |
| 2×1.5 | 8.8 | 29 | 119 |
| 3G 1.5 | 9.2 | 43 | 140 |
| 4G1.5 | 10 | 57.6 | 168 |
| 5G1.5 | 10.8 | 72 | 212 |
| 7G1.5 | 11.8 | 101 | 255 |
| 12G15 | 15.4 | 173 | 433 |
| 2X2.5 | 10 | 48 | 162 |
| 3G2.5 | 10.9 | 72 | 217 |
| 4G2.5 | 12 | 96 | 260 |
| 5G2.5 | 13 | 120 | 310 |
| 7G2.5 | 14 | 168 | 362 |
| 3G4.0 | 12.9 | 115 | 300 |
| 4G4.0 | 14 | 154 | 365 |
| 5G4.0 | 15.4 | 192 | 446 |
| 4G6.0 | 16.1 | 230 | 500 |
| 4G 10.0 | 20.8 | 384 | 807 |
| 4G16.0 | 22.8 | 614 | 1117 |
1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.
2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.
3.What does your company do regarding quality control?
1) All raw materials we selected are the highest quality.
2) Professional and skillful workers care every details in handling the producing.
3) Quality control department is specially responsible for quality checking in each process.
4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.
5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.
We are China 300/500V Heat 180 GLS Steel Armoured Silicone Rubber Cables for Increased Mechanical Stress manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
