300/500V 12cx0.75mm2 12*0.75 12 Core Cu/PVC/PVC Flat Flexible Traveling Elevator Electric Power Cable
300/500V 12cx0.75mm2 12*0.75 12 Core Cu/PVC/PVC Flat Flexible Traveling Elevator Electric Power Cable image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
300/500V 12CX0.75MM2 CU/PVC/PVC Flat Traveling elevator cable
Cable Feature:
1. Conductor: Class 5 flexible copper conductor
2. Insulation: PVC (Polyvinyl Chloride)
3. Sheath: PVC (Polyvinyl Chloride)
4. Cores: 6 12 18 20 24 Cores or Others
5. Voltage: 300/500V
6. Temperature Rating:-20°C to +70°C
7. Minimum Bending Radius:8 x overall diameter
PVC Elevator Cable Application:
Elevator Cable is a flat travelling PVC cable used in conveyorand hoist equipment. This cable
is suitable for internal and panoramic elevator applications with a freely suspended length up to 45 metres.
|
No. of Cores x Nominal Cross Sectional Area
|
Nominal Conductor Diameter
|
Nominal Thickness of Insulation
|
Nominal Overall Diameter
|
Nominal Copper Weight
|
Nominal Weight
|
|
Elevator Cable
|
|||||
|
4 x 0.75
|
1.2
|
0.6
|
4.2 x 12.6
|
29
|
90
|
|
8x 0.75
|
1.2
|
0.6
|
4.2 x 23.2
|
58
|
175
|
|
12x 0.75
|
1.2
|
0.6
|
4.2 x 33.8
|
86
|
260
|
|
18x 0.75
|
1.2
|
0.6
|
4.2 x 50.2
|
130
|
380
|
|
24x 0.75
|
1.2
|
0.6
|
4.2 x 65.6
|
172
|
490
|
|
4 x 1.00
|
1.4
|
0.7
|
4.4 x 13.4
|
38
|
105
|
|
5×1.00
|
1.4
|
0.7
|
4.4 x 15.5
|
48
|
120
|
|
8 x 1.00
|
1.4
|
0.7
|
4.4 x 24.8
|
77
|
205
|
|
12x 1.00
|
1.4
|
0.7
|
4.4 x 36.2
|
115
|
300
|
|
18x 1.00
|
1.4
|
0.7
|
4.4 x 53.8
|
208
|
450
|
|
24x 1.00
|
1.4
|
0.7
|
4.4 x 70.4
|
230
|
590
|
Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International
Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced
20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers
We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC
Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.
We are China 300/500V 12cx0.75mm2 12*0.75 12 Core Cu/PVC/PVC Flat Flexible Traveling Elevator Electric Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
