2xyray- Fr A2xyray-Fr Single Core Cu/Al Conductors XLPE Insulation PVC Sheath Aluminium Wire Awa Armouerd Power Cable

2xyray- Fr A2xyray-Fr Single Core Cu/Al Conductors XLPE Insulation PVC Sheath Aluminium Wire Awa Armouerd Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

2XYRaY- FR A2XYRaY-FR

Current

DC & AC

Insulation Material

XLPE

Sheath Material

PVC Flame Retardant

Material Shape

Round Wire

Wire Core Material

Copper or Aluminum Conductor

Certification

ISO, CCC, CE, VDE

Brand

Huadong

Product Name

Flame Retardant PVC Cable

Rated Voltage

0.6/1kv

Armour

Aluminium Wire Armoured

Standards

IEC 60502

MOQ

100m

Sample

Available

Transport Package

by Wooden Drum

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

2XYRaY- FR A2XYRaY-FR single core Cu/Al conductors XLPE insulation PVC sheath aluminium wire awa armouerd power cable

Application
These cables are designed for transfer and distribution of electrical power with nominal voltage U 0 / U 0 6/1 kV, frequency 50Hz and surroundings, which require non-proliferation of flames. 2XYRaY-FR and A2XYRaY-FR is used in power plants, industrial and switching installations, for street lighting, domestic power supply connections, in secondary distribution networks and other.
These cables are preferentially used for underground application as well as for interior installation in room and cableducts and for outdoor and applications, for indoor installations, where greater mechanical protection an protection against accidental contact is required if damaged.

Construction

Construction	According to IEC 60502-1
Conductor	solid or multi-strand Al or Cu wires class 1 or 2 acc. IEC 60228
Conductor
Insulation	XLPE COMPOUND
Inner sheath	PVC flame retardant, degree of flame retardancy
Armour	Al wires twisted concentrically
Sheath	PVC flame retardant, degree of flame retardancy category A
Color	Black

Cable Parameter

Construction data 2XYRaY-FR , A2XYRaY-FR 0.6/1 kV
Number of	insulation		Cable	2XYRaY-FR		A2XYRaY-FR
cond. andnominal cross section	sheath		diameter approx.	Mass of Cu appr.	Cable weight approx.	Mass of Al appr.	Cable weight approx.
cond. andnominal cross section	mm	mm	mm	kg/km	kg	kg/km	kg
1×25 rm	0.9	1.8	16.3	229	532	68	370
1×35 rm	0.9	1.8	17.4	325	657	95	425
1×50 rm	1	1.8	18.7	458	833	127	498
1×70 rm	1.1	1.8	20.5	648	1073	190	611
1×95 rm	1.1	1.8	22.9	885	1417	260	785
1×120 rm	1.2	1.8	24.5	1120	1699	325	896
1×150 rm	1.4	1.8	26.3	1378	2028	405	1046
1×185 rm	1.6	1.9	28.4	1770	2643	510	1371
1×240 rm	1.7	2	31.2	2327	3335	665	1656
1×300 rm	1.8	2.1	34.6	2887	4118	830	2040

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced 20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers.We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane Cables and Other Special Use Cables.

1.Are yuo a manufacturer?
Yes,we are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?

Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?

1) All raw materials we selected are the highest quality.

2) Professional and skillful workers care every details in handling the producing.

3) Quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?

Yes,OEM & ODM order is warmly welcomed.

Our technical engineers can give you the professional suggestions.

5.Can I get the sample?

Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.

We are China 2xyray- Fr A2xyray-Fr Single Core Cu/Al Conductors XLPE Insulation PVC Sheath Aluminium Wire Awa Armouerd Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
