2X6mm2 6mm2 2 Core 6mm UV Resistant Solar Panel Cables Wire

2X6mm2 6mm2 2 Core 6mm UV Resistant Solar Panel Cables Wire image

Get Latest Price Request a quote

Product Details

Model NO.

solar cable

Sheath Material

XLPE/Xlpo

Insulating Material

Xlpo

Conductor Type

Stranded

Brand

Huadong

Wire Core Material

Stranded Copper

Rated Voltage

DC 1500V

Hot Sale Size

1.5mm 4mm 6mm 10mm 16mm

Temperature

-40 Deg to 125 Deg C

Standards

TUV/UL

Type

H1z2z2-K

Sample

Available

Color

Black Red or Others

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

2 core 6mm 2*6mm uv resistant solar dc cable

Solar Cable Feature:1. Conductor: Class 5 tinned annealed stranded copper
2. Insulation:120°C XLPE/XLPO,black3. Jacket:120°C XLPE , black or red
4. Cores: Single Core or Twin Core
5. Voltage: 600/1000V,1000/1500V DC
6. Temperature Rating: -40ºC~90ºC(Max 120 ºC)Solar Cable Application:
Is Used In Photovoltaic Power Generation And Solar System,Interconnects Solar Modules And ElectricalComponents
In The Photovoltaic System,Suitable For Outdoor Extreme Environments,UV,Ozone,Hydrolysis Resistant.
Parameters for Solar PV Cable

Size	Cross Section	Conductor Structure	Outer Diameter	Max. DC Resistance at 20ºC	Rated Voltage	Rated Current
Size	mm2	mm	mm	Ω/km	V	A
Single Core Solar Cable
1×2.5mm2	2.5mm2	49xΦ0.25	5.1	8.06	1000/1500	30
1×4.0mm2	4.0mm2	56xΦ0.285	6.1	4.97	1000/1500	50
1×6.0mm2	6.0mm2	78xΦ0.3	6.4	3.52	1000/1500	70
1x10mm2	10mm2	74xΦ0.4	7.3	2.12	1000/1500	95
1x16mm2	16mm2	224xΦ0.3	10.2	1.24	1000/1500	132
Dual-Core Solar Cable
2×2.5mm2	2.5mm2	49xΦ0.25	5.1×10.9	8.06	1000/1500	30
2×4.0mm2	4.0mm2	56xΦ0.285	6.1×12.3	4.97	1000/1500	50
2×6.0mm2	6.0mm2	78xΦ0.3	6.4×12.9	3.52	1000/1500	70

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International
Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters,With Advanced
20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers
We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC
Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.

We are China 2X6mm2 6mm2 2 Core 6mm UV Resistant Solar Panel Cables Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
