2kv UL4703 Standard Copper 8AWG PV Cable

2kv UL4703 Standard Copper 8AWG PV Cable image

Get Latest Price Request a quote

Product Details

Model NO.

PV Cable

Application

Solar Indusry

Conductor Material

Copper or Aluminum Alloy

Sheath Material

Crosslinking

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

Solar Indusry

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Rne Da

Color

as Requested

Standard

UL4703 or TUV

Temperature

-40ºC to 90ºC

Certificate

UL and TUV

Voltage

2000V

Conductor

Stranded Copper or Aluminul Alloy Conductor

Transport Package

Roll, Coil, Sandard Rxpot Wooden Drums

Specification

12AWG-2000kcmil

Trademark

RNE DA

Origin

Hebei, China (Mainland)

HS Code

8544422900

Production Capacity

5000 Kilometer/Kilometers Per Month

Product Description

2KV UL4703 Standard Copper 8AWG PV Cable

Product Description

Applications
• For use in solar power applications per NEC Article 690
• Rated 90 ˚C for exposed or concealed wiring in wet or dry locations
• Rated for direct burial conduit

Construction Details

• Aluminum conductors are AA-8000 series aluminum alloy, compact stranded
• XLPE insulation
• -40˚C to +90˚C
• Sunlight resistant
• RoHS compliant
• Direct burial

Specifications

Aluminum Photovoltaic Wire meets the requirements of the following:
• UL Subject 4703 for TYPE PV
• UL 44 for TYPE RHW-2
• UL 854 for TYPE USE-2

Data Sheet 1000V/2000V

Size	Diameter of conductor	Min. Number of Strands	Insulation Thickness	Nominal O.D.	Net Weight	Maximum conductor resistance at temperature 20ºC
AWG or kcmil	mm	n	mm	mm	kg/km	Ω/km
12	2.16	7	1.90	6.0	46	8.880
10	2.72	7	1.90	6.5	56	5.590
8	3.40	7	2.15	7.7	80	3.520
6	4.29	7	2.15	8.6	102	2.210
4	5.41	7	2.15	9.7	135	1.390
3	6.02	7	2.15	10.3	156	1.100
2	6.81	7	2.15	11.1	183	0.875
1	7.59	18	2.66	12.9	244	0.693
1/0	8.53	18	2.66	13.9	286	0.550
2/0	9.55	18	2.66	14.9	337	0.436
3/0	10.74	18	2.66	16.1	400	0.346
4/0	12.07	18	2.66	17.4	477	0.274
250	13.21	35	3.04	19.3	579	0.232
300	14.48	35	3.04	20.6	665	0.194
350	15.65	35	3.04	21.7	750	0.166
400	16.74	35	3.04	22.8	836	0.145
450	17.78	35	3.04	23.9	914	0.129
500	18.69	35	3.04	24.8	1028	0.116
550	19.69	58	3.43	26.6	1133	0.1060
600	20.65	58	3.43	27.5	1217	0.0967
650	21.46	58	3.43	28.3	1298	0.0893
700	22.28	58	3.43	29.1	1382	0.0829
750	23.06	58	3.43	29.9	1463	0.0774
800	23.83	58	3.43	30.7	1543	0.0725
900	25.37	58	3.43	32.2	1707	0.0645
1000	26.92	58	3.43	33.8	1871	0.0580
