Product Details

Model NO.

HTA CABLE

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PE/HDPE/MDPE

Material Shape

Round Wire

Wire Core Material

Aluminium Conductor

Certification

ISO, CCC, CE, VDE

Model

ABC Cable

Brand

Huadong

Product Name

Torsade Hta Cable

Conductor

Aluminium or Copper

Rated Voltage

12/20kv 18/30kv 19/33 (36) Kv

Cores

1 or 3 Cores

Standards

NFC 33226/NFC33-226/IEC 60228

MOQ

200m

Warranty

100% Qualified

Color

Black

Price

Get Within 12 Hours

Transport Package

by Wooden Drum

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

NFC33-226 12/20(24kV) TORSADE EDR HTA Cable

Application
NFC 33-226 CIS HTA Cables are suitable for MV power cable applications,particularly for connections in transformer stations and power stations, between aerial lines and transformer stations.
UV Resistance Flame retardant RODENT PROOF/EVA (Rodent Repellent and Termite Resistant) Sheath you can choose!
Customized size,cable construction,logo ect Available!

NF C33-226	outer	Max DC Resist.	Max. tensile	Bending radius		Weight
12/20 kV	Diameter	/km	strength	(mm)		Approx.
Section mm’	(mm)		(daN)			(kg/km)
single core cables
50	29	0.641	150	377	754	700
95	32	0.32	285	416	832	950
150	32	0.206	450	416	832	1000
240	36.5	0.125	720	475	950	1400
400	42	0.078	1200	546	1092	1950
630	52.5	0.047	1890	683	1365	3100
1200	66	0.025	360o	858	1716	5200
3 core bunched cables
3x1x50	62.5	0.641	450	377	754	2100
3x1x95	69	0.32	855	416	832	2800
3x1x150	69	0.206	1350	416	832	3050
3x1x240	78.5	0.125	2160	475	950	4150
3x1x400	90	0.078	3600	546	1092	5800

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 15,0000 Square Meters, With Advanced 20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers.We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.

1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?
1) All raw materials we selected are the highest quality.
2) Professional and skillful workers care every details in handling the producing.
3) Quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.

We are China 24kv 30kv 36kv 1X150 1X185 1X240 mm2 Longitude Aluminium Plastic Tape Waterblocking Waterproof Rodent Proof NF C 33-226 Hta Cis Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
