23kv 1X4/0AWG ABC ACSR Tree Wire Medium Voltage Covered Conductor Mvcc Cable for Philippines Market

23kv 1X4/0AWG ABC ACSR Tree Wire Medium Voltage Covered Conductor Mvcc Cable for Philippines Market image

Get Latest Price Request a quote

Product Details

Model NO.

ABC

Current

AC Cable

Insulation Material

XLPE

Sheath Material

Material Shape

Round Wire

Wire Core Material

AAC AAAC ACSR

Certification

ISO, CCC, CE

Model

Underground Cable

Brand

Qifan

Standard

IEC 60502-2

Color

Black

Core

Conductor

Class 2 Aluminum

Conductor Screen

Semi-Conducting Compound

Nominal Operating

Short Circit

(Max.for 5sec.)250 Degree Centigrade

Using

Overhead Power Transmission

Transport Package

Export Drum

Specification

350mcm

Trademark

Qifan

Origin

China

Production Capacity

20000km/Month

Product Description

35kv 336.4mcm ACSR/XLPE/HDPE Tree Wire Overhead Cable

XLPE covered cable is constituted by a compact round conductor, composed by aluminum strands, blocked or not, with
a cross-linked polyethylene (XLPE) covered black or gray color.

The XLPE covered aluminum cable- 25kV Voltage Class is constituted by a compact round conductor, composed by alu
minum strands, blocked or not, and with a cross-linked polyethylene (XLPE) covered in black or gray color, with special
characteristics to be resistant against electric tracking and UV-rays.

As XLPE is a thermoses material, it enables operation up to 90°C continuously implying in higher capacity when compar
ed to the thermoplastic materials.

The main application for covered aluminum cables is on compact overhead, primary power distribution, medium-voltage
networks located in urban and wooded areas. These cables are an excellent technical and economic option for compan
ies all over the world, since they feature such advantages as low manufacturing cost and ease of installation.

Cross section	No. of wires	Conductor dia.	Overall Diameter	Minimum breaking load	Approx. weight	Max. DC-resistanceat 20°C	Ampacity 90°C
[mm²]		[mm]	[mm]	[kgf]	[kg/km]	[Ohm/km]	[A]
35	7	7.1	15.7	464	235	0.868	186
50	7	8.2	16.8	663	305	0.641	224
70	19	9.7	18.3	928	370	0.443	280
95	19	11.5	20.1	1259	460	0.32	343
120	19	12.9	21.5	1591	560	0.253	397
150	19	14.2	22.8	1988	650	0.206	450
185	37	16.2	24.8	2452	770	0.164	519
240	37	18.4	27	3182	960	0.125	617
300	37	20.7	29.3	3977	1155	0.1	712

We are China 23kv 1X4/0AWG ABC ACSR Tree Wire Medium Voltage Covered Conductor Mvcc Cable for Philippines Market manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
