23kv 4/0awg abc acsr tree wire
Construction
Conductors are concentrically stranded, AAC (1350-H19), either compressed or full compact depending on conductor size,
AAAC or ACSR. Available with high-density track-resistant polyethylene (HDTRPE) or Track-Resistant Crosslinked
Polyethylene(XLPE) covering. Strand shield option available as shown in illustration.
tree limbs or other objects contact conductors in such close proximity. The resulting close-proximity configuration minimizes
the amount of space and hardware required for line installation; particularly useful in congested areas such as alleyways or
tight corridors.
| Size (AWG or kcmil) | Stranding | Conductor Diameter (mils) | Covering Thickness (mils) | Cable O.D. (mils) | Rated Strength (lbs) | Weight per 1000 ft. (lbs) |
||
| Conductor Shield |
Inner Layer | Outer Layer | ||||||
| 4 | 6/1 | 250 | 15 | 75 | 75 | 580 | 1767 | 151 |
| 2 | 6/1 | 316 | 15 | 75 | 75 | 646 | 2708 | 202 |
| 1/0 | 6/1 | 398 | 15 | 75 | 75 | 728 | 4161 | 278 |
| 2/0 | 6/1 | 447 | 15 | 75 | 75 | 777 | 5045 | 330 |
| 3/0 | 6/1 | 502 | 15 | 75 | 75 | 832 | 6289 | 393 |
| 4/0 | 6/1 | 563 | 15 | 75 | 75 | 893 | 7933 | 471 |
| 266.8 | 18/1 | 609 | 15 | 75 | 75 | 939 | 6536 | 474 |
| 266.8 | 26/7 | 642 | 15 | 75 | 75 | 972 | 10735 | 553 |
| 336.4 | 18/1 | 684 | 15 | 75 | 75 | 1014 | 8246 | 570 |
| 336.4 | 26/7 | 720 | 15 | 75 | 75 | 1050 | 13395 | 669 |
| 336.4 | 30/7 | 741 | 15 | 75 | 75 | 1071 | 16435 | 935 |
| 397.5 | 18/1 | 743 | 15 | 75 | 75 | 1073 | 9443 | 653 |
| 397.5 | 24/7 | 772 | 15 | 75 | 75 | 1102 | 13870 | 707 |
| 397.5 | 26/7 | 783 | 15 | 75 | 75 | 1113 | 15485 | 770 |
| 477 | 24/7 | 846 | 15 | 75 | 75 | 1176 | 16340 | 824 |
| 477 | 26/7 | 858 | 15 | 75 | 75 | 1188 | 18525 | 899 |
| 477 | 30/7 | 883 | 15 | 75 | 75 | 1213 | 22610 | 1274 |
| 556.5 | 18/1 | 879 | 20 | 75 | 75 | 1219 | 13015 | 874 |
| 556.5 | 24/7 | 914 | 20 | 75 | 75 | 1254 | 18810 | 949 |
| 556.5 | 26/7 | 927 | 20 | 75 | 75 | 1267 | 21470 | 1036 |
| 636 | 18/1 | 940 | 20 | 75 | 75 | 1280 | 14915 | 1200 |
| 636 | 26/7 | 990 | 20 | 75 | 75 | 1330 | 23940 | 1373 |
Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International
Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 15,0000 Square Meters, With Advanced
20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers
We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC
Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.
1.what is our payment term ?
Our payment term is usually T/T 30% advanced, the balance paid before picking up the goods or L/C at sight.
2.what is the lead time ?
The lead time usually is 10 – 30 working days.
3.what is the package of the cable ?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.
4.Could we provide the free sample for customer ?
Sure, we provide the free sample for customer to checking.
We are China 23kv 1X4/0AWG ABC ACSR Tree Wire Medium Voltage Covered Conductor Mvcc Cable for Philippines Market manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
