Product Details

Model NO.

MC Cable

Current

DC & AC

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Aluminium Conductor

Certification

RoHS

Brand

Huadong

Rated Voltage

600V

Size

14 12 AWG

Standard

UL/IEEE

Sample

Available

Cores

2 3 4 5 7 9 12 19

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

2 3 4 5 7 9 12 19 Cores 600V UL Type MC 14 12 AWG Multi-conductor Armored Cable

APPLICATIONS:

• In all raceways or direct burial In wet or dry locations

• Permitted for use in Class I, Division II and Class II, Division II, and Class III, Division I and II per NEC Article 334

STANDARDS:

• UL 1569, UL 44, UL 1581, UL

• Type MC-600 volts

• NEC Type XHHW-2 conductors

• IEEE 1202

• OSHA Acceptable

Category Conductor Description	Bare compressed copper Class B stranding per ASTM B3 and B8
Category Insulation Description	Flame-retardant Cross-linked Polyethylene (XLPE)
Armor	Aluminum interlocked armor
Outer Jacket	Flame-retardant, moisture and sunlight resistant Polyvinyl Chloride (PVC)

CABLE PARAMETERS:
For other sizes,pls contact us!
