1mm 1.5mm 2.5mm 4mm 6mm Copper Wire BVV BVVB Wire Electrical Wire Cu/PVC/PVC Nyify

1mm 1.5mm 2.5mm 4mm 6mm Copper Wire BVV BVVB Wire Electrical Wire Cu/PVC/PVC Nyify image

Get Latest Price Request a quote

Product Details

Model NO.

BVVB

Application

Light

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Building

Certification

ISO9001, CCC

Brand

Zoom Link

Type of Conductor

Solid , Stranded, Flexible

Insulation

PVC

Voltage

300/500V, 450/750V

MOQ

20000m

OEM or ODM

Samples

Free

Type of Company

Manufacture

Price

Factory Price

Quality

100% Test Each Drum

Delivery Time

30 Days

Transport Package

Coil

Specification

1.5mm, 2.5mm, 4mm, 6mm

Trademark

ZML

Origin

China

Production Capacity

200000 Per Day

Packaging & Delivery

Package Size

100.00cm * 100.00cm * 100.00cm

Package Gross Weight

600.000kg

Product Description

1mm 1.5mm 2.5mm 4mm 6mm Copper Wire BVV BVVB wire Electrical Wire CU/PVC/PVC NYIFY

Twin and Earth Cable CU/PVC/PVC NYIFY

Twin and earth cable comprises two individually insulated current carrying conductors and an uninsulated circuit protective conductor. Twin and Earth cable is the most common cable used for domestic wiring today.

The sheath is either grey (PVC) or white for low smoke cables (OHLS).

Flat Twin and Earth CU/PVC/PVC NYIFY

Also known as FTE (flat twin and earth) the live and neutral conductors are individually insulated, and the Circuit Protective Conductor (CPC) or earth, is bare. Not suitable for unprotected use outside as the outer sheath materials are vulnerable to attack by UV although protective paint can provide some UV protection.

Standard metric twin and earth cable sizes are:

1mm² 1.5mm² & 2.5mm² which have solid (non-stranded) conductors
4mm², 6mm², 10mm², 16mm² and higher have stranded conductors
1.5mm² is used typically for domestic wiring circuits and 2.5mm² twin and earth is used in domestic power circuits

VOLTAGE	300/500V
CONDUCTOR	1mm2 to 2.5mm2: Class 1 Solid Copper 4mm2 to 16mm2: Class 2 Stranded Copper	1mm2 to 2.5mm2: Class 1 Solid Copper 4mm2 to 10mm2: Class 2 Stranded Copper
CIRCUIT PROTECTIVE CONDUCTOR	1mm2 to 2.5mm2: Class 1 Solid Copper 4mm2 to 16mm2: Class 2 Stranded Copper
INSULATION	PVC (Polyvinyl Chloride)	XLPE (Cross-Linked Polyethylene)
OUTER SHEATH	PVC (Polyvinyl Chloride)	LSZH (Low Smoke Zero Halogen)

1. Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first beginning to the last.
Welcome to visit us. We’ll pick you up in Zhengzhou

2. How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.

3. What’s your Minimum Order Quantity?
Normally 1000m. However, the cable is very heavy.
You’d better order a suitable quantity to avoid the high freight.
Sea transportation is the best option.

4. Can I get a discount?
It depends on your quantity, We can make a discount and afford the freight. Pls kindly contact us.

5. Does your company accept OEM production?
Yes, could print your company name, we even custom the quality card to promote your company.
