15kv 25kv 35kv AAC /AAAC/ACSR /XLPE /HDPE Power Cable

15KV 25KV 35KV AAC /AAAC/ACSR /XLPE /HDPE power cable

 Structure:

Conductors are concentrically stranded, AAC (1350-H19), either compressed or full compact depending on conductor size, AAAC or ACSR. Available with high-density track-resistant polyethylene (HDTRPE) or Track-Resistant Crosslinked Polyethylene (XLPE) covering. Strand shield option available as shown in illustration.

 Application:

 Used for primary and secondary overhead distribution where limited space is available or desired for rights-of-way. Installed the same as bare conductors, however, covering is effective in preventing direct shorts and instantaneous flashovers should tree limbs or other objects contact conductors in such close proximity. Tree Wire – Used for spans where trees crowd the right-of-way, such as in wooded residential areas, when a minimum of interference with the environment is desired. Covering minimizes power outages due to conductor contact with tree limbs, reducing the need for frequent or severe trimming. Covered Aerial MV Cable – Installed with other Covered AerialMV cables and a supporting messenger through a series of spacemaintaining devices (spacers). The resulting close-proximity configuration minimizes the amount of space and hardware required for line installation, particularly useful in congested areas.

Standard :35kV covered multi-layer tree wire meets or exceeds all applicable ICEA specifications and the following ASTM
