1500V PV Xlpo Insulation TUV Power Wire 4mm 6mm Solar Cable

1500V PV Xlpo Insulation TUV Power Wire 4mm 6mm Solar Cable image

Get Latest Price Request a quote

Product Details

Model NO.

h2z2z2-k

Application

Heating, Building

Conductor Material

Tinned Copper

Sheath Material

Xlpo

Insulation Material

Xlpo

Material Shape

Round Wire

Range of Application

Conduit or Recognized Raceways for Services

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Huatong

Voltage

1500V

Certificate

TUV

Application Area

Solar Energy/Photovoltaic/New Energy Sector

Product Characteristics

UV Resistance, Anti-Oxidation/Corrosion Preventive

Transport Package

Coils and Drums

Specification

2.5mm2-240mm2

Trademark

HT CABLES

Origin

China

HS Code

8544492100

Production Capacity

200000m/Month

Product Description

Electric cables for photovoltaic systems DC 1.5kV
DC 1.5kV

Tinned soft copper conductor XLPO insulation XLPO sheath
Application
Cables for use in photovoltaic systems,in partcular for installation at Direct Current side.
.
Construction
Conductor : Tinned soft copper conductor
Insulation : LSZH XLPO insulation
sheath : LSZH XLPO sheath

Marking text : TÜV EN 50618 H1Z2Z2-K DC 1.5kV 1×** mm² Hebei Huatong
Wires & Cables Group Co., Ltd. 2023 ****m
Rated voltage (Uo) : DC1.5kV;AC 1.0/1.0kV
Highest system voltage (Um) : 1.8kV

Core Identification
Insulation : Blac/White
Outer Sheath Colours
Available colours : Black/Red

*other colours available on request
Installation recommendations
Min. Bending Radius during Installation : 8xD (D is diameter of cable)
Min. Bending Radius Fix Installed : 6xD (D is diameter of cable)
Max. Conductor Operating Temperature : 90°C

Standards applied
EN 60332-1-2
EN 60811-501
EN 50618

Vertical flame propagation
Wrethering/UV Resistant test
Electric cables for photovoltaic systems

1	2	3	4	5
Nominal cross sectiona area of conductors (mm²)	Nominal thickness of Insulation (mm)	Nominal thickness of sheath (mm)	Approx. dia. (mm)	Approx. Weight (kg/km)
1.5	0.7	0.8	4.6	36.2
2.5	07	0.8	5.0	47.3
4	0.7	0.8	5.5	61.4
6	0.7	0.8	6.0	81.1
10	0.7	0.8	7.0	125.7
16	0.7	0.9	8.6	186.3
25	0.9	1.0	10.5	280.6
35	0.9	1.1	13.0	411.9
50	1.0	1.2	15.1	548.1
70	1.1	1.2	17.2	761.1
95	1.1	1.3	18.6	948.6
120	1.2	1.3	20.6	1209.7
150	1.4	1.4	23.4	1498.4
185	1.6	1.6	25.5	1821.7
240	1.7	1.7	28.7	2398.1

We are China 1500V PV Xlpo Insulation TUV Power Wire 4mm 6mm Solar Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
