15000V 15kv High Voltage Type Shd-Gc 3/C Mold-Cured CPE Jacket Amercable 3/C Mining Cable

15000V 15kv High Voltage Type Shd-Gc 3/C Mold-Cured CPE Jacket Amercable 3/C Mining Cable image

Get Latest Price Request a quote

Product Details

Model NO.

SHD-GC

Current

DC & AC

Insulation Material

Rubber

Sheath Material

Rubber

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CE, VDE, ASTM/Icea

Brand

Huadong

Product Name

Mine Power Cable

Core

3 Cores or as You Need

Rated Voltage

2 5 8 15 Kv

MOQ

100m

Transport Package

by Wooden Drum

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

15000V 15KV High Voltage TYPE SHD-GC 3/C MOLD-CURED CPE JACKET Amercable 3/C mining cable

Application:
Heavy duty high voltage portable power cable for use in circuits not exceeding the rated voltage. These cables are used for heavy mobile equipment such as drag lines, shovels, dredges, drills and for power feeders.Recommended maximum continuous conductor temperature in 90ºC .Suitable for shallow water submersion.

Standard:
ICEA S-75-381/NEMA WC 58
ASTM B 172
ASTM B 33
CAN/CSA-C22.2 No.96

Construction:

Conductors: Stranded annealed tinned copper conductor.

Conductor Shield:Semi-conducting layer.

Insulation:EPR.

Insulation Shield:Non-conducting tape + Tinned copper/textile braid.

Ground Check Conductor:Tinned copper with a yellow polypropylene insulation.

Grounding Conductor:Tinned copper conductor.

Sheath: Reinforced extra-heavy-duty Chlorinated Polyethylene(CPE), black. Other sheath materials can be offered upon request.

Options:Other jacket materials such as TPU/CSP/PCP/NBR/PVC are available upon request.Two-layer jacket with reinforcing fibre between the two layers can be offered as an option.

1.You are manufacturer or trader ?

We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?

Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?

1) All raw materials we selected are the highest quality.

2) Professional and skillful workers care every details in handling the producing.

3) Quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?

Yes,OEM & ODM order is warmly welcomed.

Our technical engineers can give you the professional suggestions.

5.Can I get the sample?

Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.

We are China 15000V 15kv High Voltage Type Shd-Gc 3/C Mold-Cured CPE Jacket Amercable 3/C Mining Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
