Product Details

Model NO.

NMD90

Application

Solar Indusry

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Solar Indusry

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Rne Da

Conductor

Copper

Insulation

PVC

Sheath

PVC

UL719

Length

250FT 150m 75m

Packing

Roll

Market

The Us, Canada

Color

White, Orange, Yellow Black

Working Temperature

Wire Type

Nm-B Nmd90

Transport Package

Roll, Coil, Sandard Rxpot Wooden Drums

Specification

12AWG-2AWG

Trademark

RNE DA

Origin

Hebei, China (Mainland)

HS Code

8544422900

Production Capacity

5000 Kilometer/Kilometers Per Month

Packaging & Delivery

Package Size

20.00cm * 20.00cm * 20.00cm

Package Gross Weight

1.000kg

Product Description

NMD90 Wire Non Metallic Sheathed Cable Outdoor

Applications

NMD90 cables may be used for both exposed work in dry locations or concealed work in dry or damp locations.
The maximum allowable conductor temperature is 90°C. The minimum recommended installation temperature is -25°C for two-conductor
cables and -10°C for three-conductor cables (with suitable handling procedures). Material should be properly stored above 0°C for
24 hours prior to installation.
The maximum voltage rating for all intended applications is 300 volts. Consult the Canadian Electrical Code1 for further
information related to applications.

Standards

Type NMD90 cable complies with:
ASTM
Canadian Standard C22.2 No. 48 (non-metallic sheathed cable)
Canadian Electrical Code1

Specifications

NMD90 jackets which reduces the coefficient of friction, allowing cables to be installed without external lubricants, resulting in reduced labour and materials costs.
• COPPER CONDUCTORS
• 300 VOLTS / -25ºC MIN, 90ºC MAX

Construction

Nonmetallic-sheathed Cable NMD90

NMD90 cables are available as two- or three-conductor cables with a bare grounding conductor. It is manufactured using annealed
(soft) copper conductors-compressed standing for stranded conductors; a heat-resistant thermoplastic polyvinyl chloride (PVC)
insulation and nylon jacket for the individual conductors with a PVC jacket for the overall construction.
Conductors are white, black and red (for 3 conductor cables). Cable jackets are colour coded by size for quick identification in
the Table below:

JACKET COLOUR CODE – Typical Application Guide
•WHITE – General Residential Wiring
•RED – 2 Black and Red conductors – 208V-240V Circuits (no neutral)
•ORANGE – No. 10 AWG General Residential Wiring
•YELLOW – No. 12 AWG General Residential Wiring
•BLUE – No. 14 AWG – 2 black and white conductors – 120V Arc Fault Circuit Interupter Applications

NMD90 jackets which reduces the coefficient of friction, allowing cables to be installed without external
lubricants, resulting in reduced labour and materials costs.

Product Paramenters

Conductor			Insulation		Ground
Size (AWG)	Cores	Strands	Inches	mm	Size (AWG)	Core
14	2	1	0.034	0.86	14	1
14	2	1	0.034	0.86	14	1
12	2	1	0.034	0.86	14	1
10	2	1	0.034	0.86	12	1
8	2	7	0.040	1.02	10	1
6	2	7	0.051	1.30	8	7
14	3	1	0.034	0.86	14	1
12	3	1	0.034	0.86	14	1
10	3	1	0.034	0.86	12	1
8	3	7	0.040	1.02	10	1
6	3	7	0.051	1.30	8	7
3	3	7	0.051	1.30	6	7

Approx. Jacket thickness		Approx. Cable Dia.		Approx. Cable weight		Allowabl e Ampaciti es 30°C
Inches	mm	Inches	mm	Ib/ 1000ft	Kg/ km
0.030	0.76	0.388*0.192	9.86*4.88	68	101	25*
0.030	0.76	0.388 x 0.192	9.86 x 4.88	68	101	25*
0.030	0.76	0.422 x 0.209	10.71 x 5.30	86	129	30*
0.030	0.76	0.481 x 0.230	12.21 x 5.84	122	182	40*
0.045	1.14	0.636 x 0.312	16.15 x 7.92	208	310	55
0.045	1.14	0.792 x 0.370	20.12 x 9.40	315	468	75
0.030	0.76	0.345	8.77	86	128	25*
0.030	0.76	0.381	9.69	114	169	30*
0.030	0.76	0.427	10.85	163	242	40*
0.045	1.14	0.570	14.47	275	408	55
0.045	1.14	0.695	17.65	421	627	75
0.080	2.03	0.925	23.48	799	1189	115
