12/3 Flexible Copper Wire Sjoow 300V

12/3 Flexible Copper Wire Sjoow 300V image

Get Latest Price Request a quote

Product Details

Model NO.

18 awg -2 awg

Application

Overhead, Power Cord. Home Appliance and Movable Tools.

Conductor Material

Copper

Sheath Material

CPE

Insulation Material

Epr

Material Shape

Round Wire

Range of Application

Industrial Equipment, Heavy Tools, Battery Charger

Certification

ISO9001, CE, CCC, RoHS, VDE, UL cUL CSA

Brand

Rneda

Cable Type

Sjoow Soow

Standard

UL 62

Characteristic

Oil Resistant

Core No.

3 Core, 4 Core, 5 Core

RoHS

Yes

Msha

Yes

Insulation

Epr EPDM

Size

18AWG, 16AWG, 14AWG, 10AWG, 8AWG, 6AWG, 4AWG, 2AWG

Color

Black

Transport Package

Soft Packing or Standard Export Drum

Specification

18AWG-2AWG

Trademark

RNE DA

Origin

Hebei, China (Mainland)

HS Code

8544492100

Production Capacity

100000 Meters Per Week

Product Description

12/3 Flexible Copper Wire Sjoow 300V

The largest UL cable manufacturer in China

Top 10 Cable manufactuer in China.

Largest Rubber cable manufacturer in China.
Leading ESP cable manufacturer.
Professional OEM manufacturer.
With UL,TUV,KEMA,CE,BV,PSB,SABS,MSHA,GL,NKK,KR,DNV,CCS certifications.
With TUV TYPE TESTING REPORT.

With ISO9001,ISO14001,ISO45001 syetem certifications.
ISO 17025 standard and CNAS approval laboratory.

1 Applications:

UL S/SO/SOW/SOOW Electric Cable is ideal for use with industrial equipment, heavy tools, battery chargers,portable lights and power extensions. SOOW cable has a neoprene insulation that is resistant to oil,acid, abrasion, sunlight.

2 Standard:

UL62 Standard.

Core of conductor	Size AWG /Kcmil	Nominal Insulation		Nominal Sheath		Overall	Weight	Max. DC resistance at 20C (Ω/km)
		Thickness		Thickness		Diameter
		mil	mm	mil	mm	mm	kg/km
2	18	30	0.76	30	0.76	7.2	72	22.40
3	18	30	0.76	30	0.76	7.6	87	22.40
4	18	30	0.76	30	0.76	8.4	107	22.40
5	18	30	0.76	30	0.76	9.2	129	22.40
2	16	30	0.76	30	0.76	7.8	90	14.10
3	16	30	0.76	30	0.76	8.3	111	14.10
4	16	30	0.76	30	0.76	9.1	137	14.10
5	16	30	0.76	30	0.76	10.1	166	14.10
2	14	30	0.76	30	0.76	8.6	115	8.88
3	14	30	0.76	30	0.76	9.2	144	8.88
4	14	30	0.76	30	0.76	10.1	180	8.88
5	14	30	0.76	30	0.76	11.1	219	8.88
2	12	30	0.76	45	1.14	10.3	172	5.58
3	12	30	0.76	45	1.14	11.0	214	5.58
4	12	30	0.76	45	1.14	12.0	266	5.58
5	12	30	0.76	45	1.14	13.2	322	5.58
2	10	45	1.14	60	1.52	14.0	304	3.51
3	10	45	1.14	60	1.52	14.9	376	3.51
4	10	45	1.14	60	1.52	16.3	467	3.51
5	10	45	1.14	60	1.52	17.9	565	3.51

Package:There are some different packing methods for different sizes, packing length and clients’ requirement

Huatong extremely focuses on doing R&D high-tech, new-type, advanced products, till now, we have obtained UL, CSA, TUV, CE, PSB, SABS, BV, KEMA certifications and ISO9001, ISO14001, ISO45001 system certifications. CNAS accredited national level laboratory.

Company name : Hebei Huatong Wires and Cables Group Co., Ltd

Establishment : 1993

Registered capital : CNY430.82 Million, equal to: US$62 Million

Plant size : 420,000SQM

Employees : 2000+

Production capacity: US$800Million

Sub-factories : in South Africa, Tanzania, Kazakhstan, Cameroon, etc.

Main products : ESP cable, mining cable, power cable up to 46KV, control cable, lift cable, shipboard cable, housing wire, and many other special cables.

Address : No.111 Huatong Avenue Fengnan Industrlal Zone Tangshan,Hebei Province, China

1. 30 years production experience and 22 years export experience .

2.Products certification :CUL UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL etc

3. OEM service available based on official & legal authorization.

4.Strict quality control system.

5.Rapid delivery and feedback Faster lead time than our competitors.

6.Excellent quality with reasonable price.

7. Strong technical support (technical data, drawing, etc.)

8.Professional teamwork service for you actively.

9.Stock available, Free sample is available.

We are China 12/3 Flexible Copper Wire Sjoow 300V manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
