12/20kv Yjlv Yjlsy Yjlsv Watertight Single Core 1X185mm Medium Voltage Aluminium Power Cable

12/20kv Yjlv Yjlsy Yjlsv Watertight Single Core 1X185mm Medium Voltage Aluminium Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

YJLSV

Current

DC & AC

Insulation Material

XLPE

Sheath Material

PE/PVC

Material Shape

Round Wire

Wire Core Material

Stranded Aluminium

Certification

HD 620 10 F, Sfs 5636

Brand

Huadong

Rated Voltage

12/20 Kv

Cores

Single Core

Type

Flame Retardancy

Size

35-630mm2

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

12/20kv Yjlv Yjlsy Yjlsv Watertight Single Core 1X185mm Medium Voltage Aluminium Power Cable

Application:
Medium voltage cables for distribution networks; also for connection to generation units and plant and process connection. To be laid directly in ground, outdoors, indoors and in cable ducts.

Standards:
DIN VDE 0276-620, HD 620 S1, IEC 60502-2 DIN VDE 0276 part 620

Construction:
Conductor:Stranded copper conductor or Al round conductor

Inner Semi-Conductive Layer:Semi-conductive material

Insulation:XLPE (Cross-Linked Polyethylene)

Outer Semi-Conductive Layer:Semi-conductive material

Swellable tape:watertight, semi-conductive

Screen:Copper wires and in external layer copper tape wrapped in counter-helix

Sheath:PVC (Polyvinyl Chloride) or rigid PE (polyethylene) compound

Sheathed color:Black

NO. OF CORES	NOMINAL CROSS SECTIONAL AREA		NOMINAL OVERALL DIAMETER	NOMINAL WEIGHT
	Conductor	Copper Wire Screen	NOMINAL OVERALL DIAMETER	NOMINAL WEIGHT
	mm2		mm	kg/km
1	50	16	33	820
1	70	16	35	930
1	95	16	36	1050
1	120	16	38	1150
1	150	25	39	1350
1	185	25	41	1500
1	240	25	44	1750
1	300	25	46	2000
1	400	35	49	2350
