12/20kv Single Core 240mm2 300mm2 400mm2 Na2xsy Rhz1 Rh5z1 Cws Power Cable

12/20kv Single Core 240mm2 300mm2 400mm2 Na2xsy Rhz1 Rh5z1 Cws Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

N2XSY CABLE

Current

DC & AC

Insulation Material

XLPE

Sheath Material

PVC/Epr

Material Shape

Round Wire

Wire Core Material

Aluminum

Certification

ISO, CCC, CE, RoHS, VDE

Model

Na2xsy

Brand

Rneda

Product Name

Na2xsy

Certifications

IEC 60502, HD620

Applicated

Underground Power Cable

Temperature

Not to Exceed 90 Degree

Conductor

Aluminum or Copper

Metal Shield

Copper Wire and Copper Tape

Pole Number

Single Pole

Sheath Color

Red or Black

Rated Voltage

18/30kv 12/20kv

Type

Mv Cable

Transport Package

Standard Export Drums

Specification

NA2XSY

Trademark

Hebei Huatong wire and cable

Origin

China

HS Code

8544492100

Production Capacity

1000000meter Per Month

Product Description

UL listed ICEA-S94-649-2004 MV URD power cable, URD cable

TOP TEN CABLE MANUFACTURER IN CHINA

LARGEST CABLE MANUFACTUER IN NORTH CHINA

WITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD’S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS

WITH TUV TYPE TESTING REPORT

WIDE PRODUCTS RANGE

ISO9001,ISO18001,OHSAS18001 SYSTEM CERTIFICATIONS

CNAS APPROVAL LABROTARY

Applications

Medium voltage power cable for static application in ground, within and outside facilities, outdoor, in cable canals, in dry areas or in water. PE sheath secures increased mechanical resistance during and after laying. Swellable tape blocks water spreading within the cable. Due to its very low factor of dielectric loss, which remains constant over its entire operating lifetime, and owing to excellent insulation property of XLPE-material, firmly longitudinally spliced with inner and external screen of semi-conductive material (extruded in one process), the cable has a high operating reliability. Used in transformer stations, switching blocks, in electric power plants and industrial plants. To avoid the effects of external impact, the adhering semi-conductive layer extruded between conductor and insulation, along with concentric copper conductor, secures restriction of electric field and resistance to partial discharges.

Standard: IEC 60502-1997 Or equivalent DIN, BS, AS/NZS, JIS, ASTM, IS, etc.
Packing: Steel or wooden Drum
Additional option :Halogen free, flame retardant, Low smoke, Anti-termite.

Construction

Conductor:	AL or Cu round conductor, multi wire stranded compacted (RM), class 2 acc. to IEC 60228
Inner screen:	extruded semi-conductive skin on conductor
Insulation:	XLPE (cross-linked polyethylene, recent mark: PE-X) compound
External screen:	extruded semi-conductive layer on insulation, longitudinally spliced with insulation (+tape of semi-conductive material)
Swellable tape:	watertight, semi-conductive
Concentric conductor:	in inner layer corrugated spirally wrapped copper wires, in external layer copper tape wrapped in counter-helix
Separating	tape
Sheath:	rigid PE (polyethylene) compound DMP 2 acc. to HRN HD 620 S1
sheath colour:	black or red

Temperature range:
during installation:	-20 °C up to +70 °C
max. operating temp.:	+90 °C
at short circuit of max. 5 s:	up to

Minimal inner bending radius:	15D
Behaviour in fire:	Halogen-free polyethylene sheath, but it is NOT self-extinguishing and fire-resistant acc. to IEC 60332-1

Product and packing pictures:
