12-2 12-3 AC90 Armoured Copper Wire

12-2 12-3 AC90 Armoured Copper Wire image

Get Latest Price Request a quote

Product Details

Model NO.

AC90

Application

Heating

Conductor Material

Copper

Sheath Material

Aia

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

Flame Retardant

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Ht Cables

Voltage

Low Voltage 600V

Armored Material

Aluminum Interlock

Certificate

cUL CSA

Core

Multicore

Working Temperature

40-+90temperature

Length

Custom Length

Transport Package

Coils and Drums

Specification

12AWG to 2000KCMIL

Trademark

HT CABLES

Origin

China

HS Code

8544492100

Production Capacity

30000m/Month

Packaging & Delivery

Package Size

111.00cm * 111.00cm * 111.00cm

Package Gross Weight

111.000kg

Product Description

Type AC90 XLPE 600V 90°C

Description

Solid Two, three or four copper conductors with low temperature XLPE insulation (RW90 XLPE) and bare copper bonding

wire. Conductor assembly paper wrapped and covered with bare interlocked aluminum armor. Rated 600 volts.

Temperature -40°C to +90°C

Approvals

CSA Spec C22.2 No. 51-M89.

Application

For open and concealed wiring in dry locations only.For use in cable troughs and ventilated flexible cable ways

in dry locations only. Minimum recommended installation temperature minus 40°C (with suitable handling procedures).

Maximum conductor temperature 90°C. Approved for use with ceiling fixtures.

Applications:

For exposed and concealed wiring in dry, locations

For use in ventilated, non-ventilated and ladder-type cable trays in dry locations

Rated at 90°C dry

Standard:

CSA C22.2 No.51-14 Armoured Cables

CSA C22.2 No. 2256 Wire and Cable Test Methods

CSA C22.2 No. 0.3 Test Methods for Electrical Wires and Cables

FT4 – Flame Test- Vertical Tray Flame Test

Structure:

Conductor: solid or stranded copper

Insulation: Cross-linked Polyethylene (XLPE) Type RW90

Bonding Conductor (Ground): bare solid or stranded copper conductor

Cable Assembly: Kraft Paper Wrap

Armour: Galvanized steel armour or AlA armour

Prints on Cable:

HT CABLES c(UL) E466697 12AWG 2C + 14AWG TYPE AC90 600V TYPE RW90 INSULATED CONDUCTOR

2022/01

Size	Conducto r type	Groundin g conductor	Insulation thickness	Approx. Armour O.D.	Approx. Weight	Reel length
AWG	–	AWG	mm	mm	Kg/km	m
14-2	Solid	14	0.76	12	170	150/75
14-3	Solid	14	0.76	12.5	200	150/75
12-2	Solid	14	0.76	12.8	203	150/75
12-3	Solid	14	0.76	13.4	245	150/75
10-2	Solid	12	0.76	14	261	150/75
10-3	Solid	12	0.76	14.6	324	150/75

We are China 12-2 12-3 AC90 Armoured Copper Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
