10kv 11kv 22kv 30kv 33kv Ect Conductor Single Core Copper Cable
10kv 11kv 22kv 30kv 33kv Ect Conductor Single Core Copper Cable image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
Copper conductor single core xlpe ht medium voltage cable
Application
They are suitable for installation mostly in power supply stations, indoors and in cable ducts, outdoors, underground and in water as well as for installation on cable trays for industries, switchboards and power stations.
Conductor: Plain annealed copper,Stranded (Class 2)
Conductor Screen: Extruded layer of semi-conducting cross-linkable compound.
Insulation: cross-linked polyethylene compound XLPE or EPR.
Insulaton Screen: Extruded layer of semi-conducting cross-linkable compound is applied over the insulation.
Metallic Layer: copper tapes or a concentric layer of copper wires or a combination of tapes and wires.
Separation Sheath (for armoured cable): PVC, PE or LSZH.
Armour (for armoured cable): Aluminium wire.
Over Sheath: PVC or MDPE. LSZH can be offered as an option.
Cable Parameters(Single Core)
|
Nom. Cross-Section Area
|
|
Armoured Cables
|
||||||
|
Nom. Insulation Thickness
|
Copper Tape Screen Area
|
Nom. Bedding Thickness
|
Nom. Armour Wire Diameter
|
Nom. Sheath Thickness
|
Approx. Overall Diameter
|
Approx. Weight
|
||
|
CU
|
AL
|
|||||||
|
mm^2
|
mm
|
mm^2
|
mm
|
mm
|
mm
|
mm
|
kg/km
|
kg/km
|
|
50
|
8
|
6.7
|
1.2
|
2
|
2.2
|
41
|
2300
|
1980
|
|
70
|
8
|
7.1
|
1.2
|
2
|
2.2
|
42.6
|
2560
|
2120
|
|
95
|
8
|
7.5
|
1.2
|
2
|
2.3
|
44.4
|
2890
|
2290
|
|
120
|
8
|
7.9
|
1.2
|
2
|
2.3
|
45.8
|
3200
|
2430
|
|
150
|
8
|
8.2
|
1.3
|
2.5
|
2.4
|
48.9
|
3760
|
2830
|
|
185
|
8
|
8.6
|
1.3
|
2.5
|
2.5
|
50.6
|
4180
|
3010
|
|
240
|
8
|
9.2
|
1.3
|
2.5
|
2.5
|
53.1
|
4830
|
3270
|
|
300
|
8
|
9.7
|
1.4
|
2.5
|
2.6
|
55.5
|
5540
|
3630
|
|
400
|
8
|
10.3
|
1.4
|
2.5
|
2.7
|
59.4
|
6680
|
4130
|
|
500
|
8
|
11
|
1.5
|
2.5
|
2.8
|
62.2
|
7790
|
4690
|
|
630
|
8
|
11.8
|
1.5
|
2.5
|
2.9
|
67.4
|
9290
|
5220
|
Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced 20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers.We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane Cables and Other Special Use Cables
1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.
2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.
3.What does your company do regarding quality control?
1) all raw materials we selected are the highest quality.
2) professional and skillful workers care every details in handling the producing.
3) quality control department is specially responsible for quality checking in each process.
4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.
5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.
We are China 10kv 11kv 22kv 30kv 33kv Ect Conductor Single Core Copper Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
