100% Pure Copper Super Flexible Rubber Welding Cable

100% Pure Copper Super Flexible Rubber Welding Cable image

Get Latest Price Request a quote

Product Details

Model NO.

H01N2D YH YHF Welding Cable

Current

DC & AC

Insulation Material

Flexible Rubber

Sheath Material

Rubber

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE, TUV

Model

H01n2d H01n2e Yh Yhf

Brand

Rneda

Certificate

CE ISO CCC TUV

Size

16mm2 25mm2 35mm2 50mm2 70mm2 95mm2

Conductor

Flexible Copper

Sheath

Double

Character

Oil Resistant

Welding Cable

H01n2d H01n2e

Usage

Arc Welder

Double Sheath

Rubber

Conductor Type

Super Flexible

Oil Resistance

Yes

Transport Package

Wooden Drum or Flexible Roll

Specification

IEC DIN ASTM VDE BS

Trademark

RNEDA

Origin

China

HS Code

8544492100

Production Capacity

500km/Month

Product Description

H01N2D H01N2E 50mm2 70mm2 100% Pure Copper Super Flex Double Insualtion Rubber Welding Cable

H01N2D H01N2E YH YHF

Welding Cable Suitable for the welding machine whose voltage to the ground is not more than 200V and pulsating current value: 400V

1. Cable Structure:

Conductor: copper, annealed copper, tinned copper, aluminum,cu,cca,ccam

Sheath of conductor: Polyester film

Sheath material: rubber , neoprene,chloroprence rubber compound,EPDM.

2.Characteristis:

   1.The cable has high flexibility properties.
   2.The sheath shall be a natural rubber compound or a chloroprence rubber compound.
   3.The chloroprene rubber sheath is heat and oil resistant and flame   retardant.

4.The permissible continuous operating temperature 65°C

3. Products characteristics:

1.Such cables can bear immersed voltage test of rated voltage 2000V for 5 minutes.

2.Such cables should not be higher than 65°C.

4. Application

Application:
Model	Name	Main applications	Working temperatureof core ≤0C
H01N2-D	Natural RubberSheath for Welding Cable	Always used indoor	65
H01N2-E	Neoprene Rubber Sheath or chloroprence rubber compound Welding Cable	Always used outdoor	65

5. Products sizes and parameters:

Conductor Nominal Section (mm2)	Conductive Core	Thickness of Section Sheath (mm)	Average Outer Diameter (mm2)		20oC Conductor Resistance≤(Ω/km)	Reference Weight(kg/km)
Conductor Nominal Section (mm2)	Number/Diameter of Core(mm)	Thickness of Section Sheath (mm)	Min	Max	20oC Conductor Resistance≤(Ω/km)	YH	YHF
10	322/0.20	1.8	7.5	9.7	1.91	146	153.51
16	513/0.20	2	9.2	11.5	1.16	218.9	230.44
25	798/0.20	2	10.5	13	0.758	316.6	331.15
35	1121/0.20	2	11.5	14.5	0.536	426	439.87
50	1596/0.20	2.2	13.5	17	0.379	592.47	610.55
70	2214/0.20	2.4	15	19.5	0.268	790	817.52
95	2997/0.20	2.6	17	22	0.198	1066.17	1102.97
120	1702/0.30	2.8	19	24	0.161	1348.25	1392.55
150	2135/0.30	3	21	27	0.129	1678.5	1698.72
185	1443/0.40	3.2	22	29	0.106	1983.8	2020.74

TOP TEN CABLE MANUFACTURER IN CHINA
LARGEST CABLE MANUFACTUER IN NORTH CHINA
ANNUAL EXPORT VOLUME EXCEED 200MILLION USD
WITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD’S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS
WITH TUV TYPE TESTING REPORT
WIDE PRODUCTS RANGE
ISO9001,ISO18001,OHSAS18001 SYSTEM CERTIFICATIONS
CNAS APPROVAL LABROTARY

We are China 100% Pure Copper Super Flexible Rubber Welding Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
