1× 500 mm2 XLPE Insulated Copper Cable Mv Cable (12.7/22kv) Termination Kit with Terminal
1× 500 mm2 XLPE Insulated Copper Cable Mv Cable (12.7/22kv) Termination Kit with Terminal image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
1×500 mm2 xlpe insulated copper cable mv cable (12.7/22kv) termination kit with terminal
Conductor: Aluminium/Copper
Insulation/Jacket: XLPE/PVC
Armoured: Galvanized Steel Wires/Steel Tape for 3 Cores
Stainless Steel Wire/Steel Tape or Aluminium Wire/Tape for Single Core
Cores: 1 Core,3 Cores
Section Area: 1.5mm2-800mm2
Standard: IEC 60502, BS 7870, GB/T12706 or other.
Packaging: Iron Or Wooden Drum
Application: Building, Engineered, Railway, Plant construction, Shool, Hospital, Underground and so on.We can customize
the size according to your requirement.
|
HIGH ELECTRICAL CONDUCTIVITY COPPER OR ALUMINIUM CONDUCTOR
Copper or aluminium stranded(Class 2) conductors according to lEC 60228
|
|
|
HIGH RESISTANCE PVC/XLPE INSULATION
Available with Cross-linked Polyethylene(XLPE)or Polyvinyl Chloride(PVC) insulation
|
|
|
UV RESISTANCE & FLAME RETARDANT PVC JACKET
Provided with flame retardant PVC jacket to pass flame propagation test to lEC60332-1
|
|
|
CUSTOMIZED DESIGNS
Available in Armoured/Non-armoured and Shielded/Non-shielded constructions
|
|
Nominal Conductor Area
|
No. and Diameter of Wires
|
Nominal Diameter of Conductor
|
Maximum Conductor Resistance at 20ºC
|
Nominal Weight/Km
|
|
mm²
|
no./mm
|
mm
|
Ω/km
|
kg
|
|
1
|
7 / 0.43
|
1.29
|
18.1
|
9.2
|
|
1.5
|
7 / 0.53
|
1.59
|
12.1
|
14
|
|
2.5
|
7 / 0.67
|
2.01
|
7.41
|
22.4
|
|
4
|
7 / 0.85
|
2.55
|
4.61
|
36.1
|
|
6
|
7 / 1.04
|
3.12
|
3.08
|
54
|
|
10
|
7 / 1.35
|
4.05
|
1.83
|
90.8
|
|
16
|
7 / 1.70
|
4.69
|
1.15
|
145
|
|
25
|
7 / 2.14
|
5.9
|
0.727
|
229
|
|
35
|
7 / 2.52
|
6.95
|
0.524
|
317
|
|
50
|
19 / 1.78
|
8.4
|
0.387
|
429
|
|
70
|
19 / 2.14
|
10.1
|
0.268
|
620
|
|
95
|
19 / 2.52
|
11.9
|
0.193
|
860
|
|
120
|
37 / 2.03
|
13.5
|
0.153
|
1086
|
|
150
|
37 / 2.25
|
14.9
|
0.124
|
1334
|
|
185
|
37 / 2.52
|
16.9
|
0.0991
|
1673
|
|
240
|
61 / 2.25
|
19.2
|
0.0754
|
2199
|
|
300
|
61 / 2.52
|
21.5
|
0.0601
|
2759
|
|
400
|
61 / 2.85
|
24.3
|
0.047
|
3528
|
|
500
|
61 / 3.20
|
27.3
|
0.0366
|
4448
|
|
630
|
127 / 2.52
|
32.76
|
0.0283
|
5744
|
|
800
|
127 / 2.85
|
37.05
|
0.0221
|
7346
|
|
1000
|
127 / 3.20
|
41.6
|
0.0176
|
9260
|
Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International
Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 15,0000 Square Meters, With Advanced
20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers
We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC
Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.
We are China 1× 500 mm2 XLPE Insulated Copper Cable Mv Cable (12.7/22kv) Termination Kit with Terminal manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
