1 2 3 4 5 Core Nc2xry Nc2xry-Cc XLPE Power Cable

1 2 3 4 5 Core Nc2xry Nc2xry-Cc XLPE Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

NCYAY

Current

DC & AC

Insulation Material

PVC

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Stranded Tinned Copper

Certification

VDE

Brand

Huadong

Rated Voltage

0.6/1kv

Cores

1 2 3 4 5 Core

Size

1.5-400mm2

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

NCYAY NCYRY NCYRY-cc NAYY NAYRY NA2XRY NA2XHRH Nigeria standard power cable

Application
Used in installations, in cable ducts/trays and in industrial plants, substations. Can also be used underground with additional protections (where mechanical damage may be expected).

Construction:
N:Standard cable type
C:Copper conductor
Y:PVC Insulation
Y:PVC Sheath

Cable Parameters

Number of cores and nominal cross section	Copper figure	Overall diameter	Weight	Current carrying	Current carrying
	Copper figure	Overall diameter	Weight	Current carrying	Current carrying
	/	appr.	appr.	capacity ground	capacity air
mm2	kg/km	mm	kg/km	A	A
1 x 16 RE	160,0	11	233,0	107	84
1 x 25 RM	250,0	12	370,0	138	114
1 x 35 RM	350,0	14	480,0	164	139
1 x 50 RM	500,0	16	640,0	195	169
1 x 70 RM	700,0	17	850,0	238	213
1 x 95 RM	950,0	19	1.120,0	286	264
1 x 120 RM	1.200,0	21	1.375,0	325	307
1 x 150 RM	1.500,0	23	1.660,0	365	352
1 x 185 RM	1.850,0	25	2.050,0	413	406
1 x 240 RM	2.400,0	28	2.634,0	479	483
1 x 300 RM	3.000,0	30	3.295,0	541	557
1 x 400 RM	4.000,0	32	4.231,0	614	646
1 x 500 RM	5.000,0	34	5.284,0	693	747
1 x 630 RM	6.300,0	42	6.850,0	777	858
2 x 1,5 RE	30,0	11	220,0	27	20
2 x 2,5 RE	50,0	12	267,0	36	25
2 x 4 RE	80,0	14	342,0	47	34
2 x 6 RE	120,0	15	412,0	59	43
2 x 10 RE	200,0	16	510,0	79	59
2 x 16 RM	320,0	18	670,0	102	79
3 x 1,5 RE	45,0	13	244,0	27	20
3 x 2,5 RE	75,0	14	294,0	36	25
3 x 4 RE	120,0	16	393,0	47	34
3 x 6 RE	180,0	17	481,0	59	43
3 x 10 RE	300,0	18	645,0	79	59
3 x 16 RE	480,0	20	872,0	102	79
3 x 16 RM	480,0	20	872,0	102	79
3 x 25 RM	750,0	25	1.350,0	133	106
3 x 35 SM	1.050,0	25	1.460,0	159	129
3 x 50 SM	1.500,0	29	1.750,0	188	157
3 x 120 SM	3.600,0	38	4.310,0	318	285
3 x 150 SM	4.500,0	42	5.310,0	359	326
4 x 1,5 RE	60,0	14	278,0	27	20
4 x 2,5 RE	100,0	15	340,0	36	25
4 x 4 RE	160,0	17	460,0	47	34
4 x 6 RE	240,0	18	570,0	59	43
4 x 10 RE	400,0	20	775,0	79	59
4 x 10 RM	400,0	20	775,0	79	59
4 x 16 RE	640,0	22	1.072,0	102	79
4 x 16 RM	640,0	22	1.072,0	102	79
4 x 25 RM	1.000,0	27	1.632,0	133	106
4 x 35 SM	1.400,0	27	1.959,0	159	129
4 x 50 SM	2.000,0	32	2.595,0	188	157
4 x 70 SM	2.800,0	36	3.488,0	232	199
4 x 95 SM	3.800,0	41	4.637,0	280	246
4 x 120 SM	4.800,0	43	5.689,0	318	285
4 x 150 SM	6.000,0	49	6.973,0	359	326
4 x 185 SM	7.400,0	54	8.663,0	406	374
4 x 240 SM	9.600,0	60	11.140,0	473	445
For other cores,pls contact us anytime!

1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?
1) all raw materials we selected are the highest quality.
2) professional and skillful workers care every details in handling the producing.
3) quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.

5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.

We are China 1 2 3 4 5 Core Nc2xry Nc2xry-Cc XLPE Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
