1.1/1.1kv AS/NZS 1802 Standard Type241.1 6mm2 Trailing Cable
1.1/1.1kv AS/NZS 1802 Standard Type241.1 6mm2 Trailing Cable image
Get Latest Price Request a quote
You May Like
Product Details
Packaging & Delivery
Product Description
Flexible Rubber Sheathed Mining Power Cable Type 241.1
Applications:
Type 241 cables are designed for main feeder cable for continuous miners, pump cable and power supply cable. Overall semiconductive screen provides protective earth for any object breaching the sheath prior to contact with power conductors.
Standards:
AS/NZS 1802:2003
AS/NZS 1125:2001
Construction:
• Conductors: Flexible tinned copper conductor, 3 Core, 3 Earths Plus Central Pilot
• Insulation: EPR
• Insulation Screen: Semiconductive Elastomer
• Cradle Separator: Semiconductive Thermosetting
• Overall Core Screen: Semiconductive PCP Filling and Covering
• Textile Reinforcement: Open Weave Braid Reinforcement
• Sheath: Heavy Duty PCP Sheath
Rate Voltage: 1.1/1.1KV
|
Nominal Conductor Area |
Nominal Diameter |
Insulation Thickness |
Earth Conductor |
Pilot Conductor |
Overall Sheath Thickness |
Nominal Overall Diameter |
Nominal Weight |
||
|
Cross Section |
Insulation Thickness |
Cross Section |
Insulation Thickness |
||||||
|
MM2 |
MM |
MM |
MM2 |
MM |
MM2 |
MM |
MM |
MM |
KG/KM |
|
10 |
4.2 |
1.5 |
1.9 |
2.6 |
0.75 |
1.0 |
3.8 |
32.3 |
1547.3 |
|
16 |
5.4 |
1.6 |
3.0 |
2.8 |
0.75 |
1.0 |
3.9 |
35.5 |
1965.3 |
|
25 |
6.9 |
1.6 |
4.7 |
2.6 |
0.75 |
1.0 |
4.2 |
39.4 |
2553.6 |
|
35 |
8.4 |
1.6 |
6.4 |
2.5 |
0.75 |
1.0 |
4.4 |
42.9 |
3146.9 |
|
50 |
9.8 |
1.7 |
8.5 |
2.6 |
1.25 |
1.0 |
4.9 |
47.1 |
3908.3 |
|
70 |
11.55 |
1.8 |
13.8 |
2.5 |
1.25 |
1.0 |
5.3 |
51.6 |
4917.2 |
|
95 |
13.22 |
2.0 |
13.8 |
3.0 |
1.25 |
1.0 |
5.8 |
57.0 |
6014.1 |
|
120 |
15 |
2.1 |
14.8 |
3.0 |
1.25 |
1.0 |
6.3 |
62.4 |
7396.7 |
|
150 |
17.1 |
2.3 |
19 |
3.5 |
1.25 |
1.0 |
6.7 |
68.7 |
9046.8 |
|
185 |
18.5 |
2.5 |
22.2 |
3.3 |
1.25 |
1.0 |
7.3 |
73.8 |
10691.6 |
|
240 |
21.5 |
2.8 |
27.15 |
3.9 |
1.25 |
1.0 |
8.0 |
83.0 |
13544.7 |
|
300 |
23.8 |
3.0 |
34.6 |
4.1 |
1.25 |
1.0 |
8.7 |
90.2 |
16245.4 |
Mining cable is Huatong’s advantage product. We can produce different standard mining cables, including SANS standard and AS/NZS standard. We exported 640/1100V Type 41, Type 61, Type61A, Type61B and Type63, also medium voltage cable Type66, Type611, Type 622 and Type633 to South Africa, Mali, Congo, Tanzania, etc. Besides, there are Type 241.1KV, Type 441, reeling cable and crane cable for Australian and New Zealand markets. High quality, competitive price and fast delivery can meet your requirements.
We are China 1.1/1.1kv AS/NZS 1802 Standard Type241.1 6mm2 Trailing Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
