0.6/1kv Ymvkf Low Voltage Class 5 Copper Flexible Electric Power Cable

0.6/1kv Ymvkf Low Voltage Class 5 Copper Flexible Electric Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

YMvKf

Current

DC & AC

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Flexible Copper

Certification

ISO, CCC, CE, VDE

Brand

Huadong

Rated Voltage

0.6/1kv

Cores

1 2 3 4 5 Core Ect

Size

1.5-400mm2

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

YMvKf Power cable 0,6/1 kV with Cu conductors, XLPE insulated and PVC sheathed

Applications
YMvKf cable is suitable for all types of industrial low voltage connections, urban grids, building installtion, etc. This cable is fire retardant and is recommended for use in public places and hazardous industries. Its flexibility makes installation substantially easier, making it highly suitable for difficult layouts.
This cable can also be used in buried installations or in tubes or outdoors without requiring additional protection.

Cable Design
Conductors: Cu, class 5 according to EN 60228
Insulation: : XLPE compound
Bedding: Extruded elastomere LSZH compound
Sheat: PVC compound, type PVC/ST

Characteristics
Test voltage: 4 Kv
Rated voltage: 0,6/1 kV
Bending radius (min): single-core – 15D;
multicore – 12D
Min. laying temperature: -5°C
Max. working temperature: 90°C
Max. short-circuit temperature: 250°C

Cable Parameters

No. OF Cores x Cross	Current Value	Nominal Overall\| Diameter	Nominal Weight
Sectional Area [mm]	(A)	[mm]	[kg/km]
3G4	42	12,2	240
3G6	54	13,4	315
3G10	75	14.8	450
3G16	100	16.8	645
3G25	127	21,4	1020
3G35	158	23,8	1345
3G50	192	27,2	1825
3G70	246	30,3	2470
4G1,5	23	11,7	185
4G2,5	32	12,2	225
4×4	42	13,2	290
4×6	54	14.7	385
4G6	54	14.7	385
4×10	75	16,3	565
4G10	75	16.3	565
4×16	100	18,8	815
4G16	100	18,8	815
4×25	127	23,8	1275
4G25	127	23,8	1275
4×35	158	250	1700
4G35	158	25,9	1700
4×50	192	30,1	2310
4G50	192	30,1	2310
4×70	246	34.8	3185
4G701	246	34,8	3185
