Product Details

Model NO.

Marine power cable

Insulation Material

Rubber

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE, VDE

Model

Marine Power Cable

Brand

Huadong

Product Name

Marine Power Distribution Cable

Rated Voltage

0.6/1kv

Size

18 14 16 12 10 2 1 1/0 2/0 3/0 4/0 AWG

Pairs

2 3 4 5 6 7 8 10 16 20 24 Pairs

Temperature Rating

110 ºC

Conductor

Stranded Tinned Copper

Insulation

Type P Rubber

Shielding

Aluminum Polyester Tape

Jacket Material

Neoprene

Armor

Bronze Wire Braid

Standard

IEEE 1580/UL 1309

Sample

Avaiable

MOQ

100 Metres

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

100 Kilometer/Kilometers Per Month

Product Description

Low Voltage 0.6/1kv Marine Power Distribution Cable

1. Conductor : Tinned Annealed Rope-Lay Stranded Copper

2. Separator Tape(If Necessary)

3. Insulation(Type P According To IEEE 1580)

4. Filler 5. Binder Tape

6. Jacket : Arctic Neoprene

7. Armor : Bronze Wire Braid

8. Jacket : Arctic Neoprene

9. Application : Suitable For Use In Commercial Marine Applications, Modu’S & Platforms,Onshore And Offshore Drilling
Platforms,FPSO, Etc.
10. Feature : Flame retardant : Superior Flexibility,Flame&Cold Resistant,,Drilling Mud Resistant,Excellent Resistance To Oil,
Abrasion, Petrochemical Fluids, Moisture & Sunlight

No. of Cores	Nominal Area	Conductor Strand	Dia. (Max.)	Thickness of Insulation	Thickness of Jacket	Thickness of Sheath	Armor and Sheath
No. of Cores	Nominal Area	Conductor Strand	Dia. (Max.)	Thickness of Insulation	Thickness of Jacket	Thickness of Sheath	Nom.Dia. Approx.	Weight Approx.
No.	AWG or kcmil	No./mm	mm	mm/inch		mm/inch	mm/inch	kg/km
3	16	19 / 0.297	1.5	0.76 / 0.030	1.14 / 0.045	1.52 / 0.060	14.6 / 0.575	320
	14	19 / 0.373	1.88	0.76 / 0.030	1.14 / 0.045	1.52 / 0.060	15.4 / 0.606	370
	12	19 / 0.470	2.36	0.76 / 0.030	1.14 / 0.045	1.52 / 0.060	16.4 / 0.646	440
	10	37 / 0.424	2.87	0.76 / 0.030	1.14 / 0.045	1.52 / 0.060	18.0 / 0.709	540
	8	37 / 0.511	3.45	1.14 / 0.045	1.52 / 0.060	2.03 / 0.080	22.5 / 0.886	810
	6	61 / 0.511	4.45	1.14 / 0.045	1.52 / 0.060	2.03 / 0.080	24.9 / 0.980	1040
	5	91 / 0.511	6.2	1.14 / 0.045	2.03 / 0.080	2.03 / 0.080	29.6 / 1.165	1440
	4	105 / 0.511	6.55	1.14 / 0.045	2.03 / 0.080	2.03 / 0.080	30.7 / 1.209	1570
	3	125 / 0.511	7.32	1.14 / 0.045	2.03 / 0.080	2.03 / 0.080	32.1 / 1.264	1740
	2	150 / 0.511	8.23	1.14 / 0.045	2.03 / 0.080	2.03 / 0.080	33.4 / 1.315	1940
	1	209 / 0.511	9.17	1.40 / 0.055	2.03 / 0.080	2.03 / 0.080	37.7 / 1.484	2500
	1/0	266 / 0.511	10.34	1.40 / 0.055	2.03 / 0.080	2.03 / 0.080	40.3 / 1.587	2950
	2/0	342 / 0.511	11.71	1.40 / 0.055	2.03 / 0.080	2.79 / 0.110	44.4 / 1.748	3660
	3/0	418 / 0.511	12.95	1.40 / 0.055	2.03 / 0.080	2.79 / 0.110	47.7 / 1.878	4260
	4/0	532 / 0.511	14.61	1.40 / 0.055	2.79 / 0.110	2.79 / 0.110	52.9 / 2.083	5300
	262	646 / 0.511	16.61	1.65 / 0.065	2.79 / 0.110	2.79 / 0.110	57.3 / 2.256	6260
	313	777 / 0.511	18.29	1.65 / 0.065	2.79 / 0.110	2.79 / 0.110	61.0 / 2.402	7230
	373	925 / 0.511	19.94	1.65 / 0.065	2.79 / 0.110	2.79 / 0.110	64.7 / 2.547	8300
	444	1110 / 0.511	21.84	1.65 / 0.065	2.79 / 0.110	2.79 / 0.110	68.8 / 2.709	9610
	535	1332 / 0.511	23.9	2.03 / 0.080	2.79 / 0.110	3.56 / 0.140	76.4 / 3.008	11640
	646	1591 / 0.511	26.14	2.03 / 0.080	3.56 / 0.140	3.56 / 0.140	82.7 / 3.256	13760

Huadong Cable Shandong Co.,Ltd is an import and export trade company located in Jinan City, Shandong Province, China, which is a branch of Henan Huadong Cable Group. Our factory occupied 150,000 square meters.We specialize in 0.6-35KV power cables,overhead ABC cables, ACSR, AAAC,control cables, welding cables, rubber cables, mining cables ect. We can provide high quality cables meet GB, IEC, BS,ICEA, ASTM, DIN, VDE and JIS standards. What’s more, We can design cables according to your requirement.

We are China 0.6/1kv Tinned Copper Sp Spb Spbs Dpn Dpnb Dpnbs Tpn Tpnb Tpnbs Fpn Fpnb Fpnbs Qpn Qpnb Marine Power Distribution Cable Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
