0.6/1kv Single Core Copper Conductor 300mcm 350mcm 400mcm 500mcm Ttu Cable

0.6/1kv Single Core Copper Conductor 300mcm 350mcm 400mcm 500mcm Ttu Cable image

Get Latest Price Request a quote

Product Details

Model NO.

LV-YJV-TTU

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Copper Conductor

Certification

ISO, CCC, CE, VDE

Model

YJV

Brand

Huadong

Product Name

4 Core Armoured Cable

Rated Voltage

0.6/1kv

Armour

Non Armoured

Standards

Ieca, BS, DIN,GB Ect

MOQ

100m

Price

Get Within 12 Hours

Transport Package

by Wooden Drum

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

0.6/1kV single core copper conductor 300MCM 350MCM 400MCM 500MCM TTU cable

The TTU cable is a copper conductor with PE / XLPE insulation and PVC sheath.
The TTU cable type conductors (600V, 2 kV) are wired and are built with soft-tempered copper, they are also insulated with
a uniform layer of thermoplastic polyethylene (PE) or cross-linked polyethylene (XLPE) material resistant to humidity and
heat, on which a polyvinyl chloride (PVC) protective cover. They are always supplied in black color and with different
forms of packaging.

HIGH ELECTRICAL CONDUCTIVITY COPPER OR ALUMINIUM CONDUCTOR Copper or aluminium stranded(Class 2) conductors according to lEC 60228
	HIGH RESISTANCE PVC/XLPE INSULATION Available with Cross-linked Polyethylene(XLPE)or Polyvinyl Chloride(PVC) insulation
UV RESISTANCE & FLAME RETARDANT PVC JACKET Provided with flame retardant PVC jacket to pass flame propagation test to lEC60332-1
	CUSTOMIZED DESIGNS Available in Armoured/Non-armoured and Shielded/Non-shielded constructions

SIZE AWG / MCM	CROSS SECTION mm2	STRANDING Number of wire x diameter mm.	INSULATION THICKNESS mm.	JACKET THICKNESS mm.	EXTERNAL DIAMETER mm.	TOTAL WEIGHT Kg/Km	AMPACITY Amp.
14	2.06	1×1.62	0.81	0.38	4.14	31.3	20
12	3.30	1×2.05	0.81	0.38	4.54	44.7	25
10	5.26	1×2.59	0.81	0.38	5.10	62.6	35
8	8,37	7 x 1,23	1,14	0,38	6,73	109,0	50
6	13,30	7 x 1,55	1,14	0,76	8,45	170,0	65
4	21,15	7 x 1,96	1,14	0,76	9,68	301,0	85
2	33,62	7 x 2,47	1,14	0,76	11,21	376,0	115
1	42,36	7 x 2,78	1,40	1,14	13,42	461,5	130
1/0	53,49	19 x 1,89	1,40	1,14	14,53	609,0	150
2/0	67,43	19 x 2,12	1,40	1,14	15,68	747,0	175
3/0	85,01	19 x 2,39	1,40	1,14	17,03	915,0	200
4/0	107,20	19 x 2,68	1,40	1,14	18,48	1132,0	230
250	127,00	37 x 2,09	1,65	1,65	21,23	1390,0	255
300	152,00	37 x 2,29	1,65	1,65	22,63	1641,0	285
350	177,00	37 x 2,47	1,65	1,65	23,89	1889,0	310
400	203,00	37 x 2,64	1,65	1,65	25,08	2137,0	335
500	253,00	37 x 2,95	1,65	1,65	27,25	2627,0	380
600	304,00	37 x 3,23	2,03	1,65	29,97	3144,0	420
650	329,00	37 x 3,37	2,03	1,65	30,95	3409,0	440
700	355,00	37 x 3,49	2,03	1,65	31,79	3593,0	460
750	380.99	61×2.82	2.03	1.65	32.18	3854.0	475
1000	506.04	61×3.25	2.03	1.65	35.94	5045.2	545

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International
Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced
20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers
We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC
Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane Cables and Other Special Use Cables.

We are China 0.6/1kv Single Core Copper Conductor 300mcm 350mcm 400mcm 500mcm Ttu Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
