0.6/1kv Cu/Hmwpe/PVDF 1X10 1X16 1X25 1X35 1X50 1X70 1X95 mm2 Single Core Cathodic Protection Cp Cable

0.6/1kv Cu/Hmwpe/PVDF 1X10 1X16 1X25 1X35 1X50 1X70 1X95 mm2 Single Core Cathodic Protection Cp Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Cathodic Protection Cable

Application

Heating, Industrial

Conductor Material

Copper

Sheath Material

PVDF

Insulation Material

Hmwpe

Material Shape

Round Wire

Certification

ISO9001, CE, CCC, VDE

Brand

Huadong

Rated Voltage

600V/1000V

Core

Single Core

Size

6-185mm2

Sample

Available

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

HMWPE Single Core Cathodic Protection Cable

Application

Cathodic Protection Cable is designed for use in cathodic protection groundbeds where the evolution of chlorine gas is expected. PVDF has excellent resistance to chemical attack.

HMWPE cable is electrically connected (directly or indirectly) to the negative output terminal of a cathodic protection power supply. This includes bond cables to a cathodically protected structure. CP Cable is used as direct earth burial DC feeder cable in cathodic protection systems.

Technical Data
Operating Voltage	0.6/1 kV
Temperature Limits	-55°C to +105°C
Inner and Outer	Available in: Red/Black
Size	6 10 16 25 35 50 70 95 mm2 or others
Minimum Bending Radius:	As per cable manufacturer datasheet
Should not be installed at temperatures below 0°C or above +60°C

Cu/HMWPE

Conductor Stranded Annealed Copper (IEC/EN 60228, Class 2)

Insulation High Molecular Weight Polyethylene (Black) Acc. to ASTM D1248 Type 3, Class C, Category 5, IEC 60502, ST7

Reference Standards 17-SAMSS-017

SnCu/PVDF/HMWPE

Conductor Stranded Annealed Tinned Copper (IEC 60228, Class 2)
Insulation Polyvinylidene Fluoride (PVDF) (Black)
Outer Sheath High Molecular Weight Polyethylene (Black) Acc. to ASTM D1248 Type 3, Class C, Category 5, IEC 60502, ST7

Reference Standards 17-SAMSS-017.

Cu/PVDF/HMWPE

Conductor Stranded Annealed Copper (IEC/EN 60228,Class 2)

Insulation Polyvinylidene Fluoride (PVDF) (Black)

Outer Sheath High Molecular Weight Polyethylene (Black) Acc. to ASTM D1248 Type 3, Class C, Category 5, IEC 60502, ST7

Reference Standards 17-SAMSS-017

Cu/HMWPE/PVC/ SWA/SWA/HMWPE

Conductor Stranded Annealed Copper (IEC 60228, Class 2)

Insulation High Molecular Weight Polyethylene (Black) Acc. to ASTM D1248 Type 3, Class C, Category 5, IEC 60502, ST7 Inner Sheath PVC (Black)

1. Armour Round Galvanized Steel Wires

2. Armour Round Galvanized Steel Wires

Outer Sheath High Molecular Weight Polyethylene (Black) Acc. to ASTM D1248 Type 3, Class C, Category 5, IEC 60502, ST7

Reference Standards 17-SAMSS-017

1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?
1) all raw materials we selected are the highest quality.
2) professional and skillful workers care every details in handling the producing.
3) quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.

5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.

We are China 0.6/1kv Cu/Hmwpe/PVDF 1X10 1X16 1X25 1X35 1X50 1X70 1X95 mm2 Single Core Cathodic Protection Cp Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
