0.6/1kv Copper/Aluminum Core XLPE Insulation PVC/PE Sheathed Steel Wire Armored Power Cable

0.6/1kv Copper/Aluminum Core XLPE Insulation PVC/PE Sheathed Steel Wire Armored Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

power cable

Current

DC Cable

Insulation Material

PVC/PE/XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Copper/Aluminum

Certification

ISO, CCC, CE

Model

Yjv32/Yjlv32

Brand

Chunbin

Type

Insulated

Conductor Type

Stranded

Conductor Material

Copper/Aluminum

Range of Application

Underground

Rated Voltage

0.6/1kv

Number of Cores

1/2/3/4/5

Insulation

PVC/PE/XLPE

Packing

Roll/Wooden Drum

Conductor

Copper/Aluminum

MOQ

500 Meters

Length

Lengths Customize

Product Name

Power Cable

Rated Temperature

90′c

Transport Package

Cartons, Wooden Wheels, Soft

Trademark

Chunbin

Origin

Luoyang, Henan

Production Capacity

300, 000m/Week

Product Description

Conductor	Copper/Aluminum
Insulation	XLPE/PVC/PE
Application	Power Transmission,Building,Railway,School,Hospital,Plant construction,Underground and so on
Rated Voltage	0.6-1KV/1-35KV
Section Area	1.5mm²–500mm²
Number of Cores	1/2/3/4/5
Armoured	Steel Wire Armoured/Steel Tape Armoured or Non Armoured
MOQ	500 Meters

Parameter

No. of Cores	Conduct Cross Section Area	Cable Cross Section Area	Actual Armour Cross Section Area	Overall Diameter	Nominal Weight	Resistance of Conductor at 20ºC
/	mm²	mm²	mm²	mm	kg/km	Ω/Km
3	1.5	124.63	16	12.6	330	12.1
3	2.5	156.07	19	14.1	390	7.41
3	4	183.76	20	15.3	464	4.61
3	6	216.31	23	16.6	568	3.08
3	10	298.5	39	19.5	866	1.83
3	16	366.25	45	21.6	1152	1.15
3	25	510.45	62	25.5	1800	0.727
3	35	615.44	68	28	2230	0.524
3	50	637.62	78	28.5	2490	0.387
3	70	813.92	90	32.2	3290	0.268
3	95	1074.67	128	37	4440	0.193
3	120	1281.25	141	40.4	5470	0.153
3	150	1625.15	201	45.5	6930	0.124
3	185	1946.83	220	49.8	8350	0.0991
3	240	2383.27	250	55.1	10400	0.0754
3	300	2844.87	269	60.2	12600	0.0601
3	400	3481.91	304	66.6	14600	0.047

Packing & Delivery

Package: Generally, pack in rolls or wooden drums. Accept customized service for free.

Rolls, Wooden Drums, Steel Drums, Reels

Delivery: Both 20GP container and 40GP container are supplied.
Air transportation, Sea transportation, Express delivery.

Our Factory

00:0

Chunbin Cable Group Co.,Ltd. was founded in 1989.it has five core subsidiaries,including copper processing,PVC cable pellets production and more than 50 cooperative enterprises,With more than 600 sales outlets nationwide.It is a specialized company integrating R&D manufacturing and sales.

Our company mainly produces:mineral insulated cable,photovoltaic cablecharging pile cable,OPLC rail transit cable, optical fiber composite cable, medium and low voltage XLPE insulated power cable, pvc insulated power cable,aluminum alloy cable,fire resistant cable,flame retardant cable,control cable. overhead insulated cable, low-smoke halogen-free cable,rubbercable,mining cable,aluminum stranded wire and steel core aluminum stranded wire,PVC insulated wire and cord,shielded monitoring line, protection More than 50 varieties, more than 1000 specifications,such as line,agricultural land embedding, anti-aging line, coaxial cable. At the same time, it can also produce British standard American standard and German standard wire and cable, and customize special type wire and cable for customers.

Certifications

Our company strictly controls the quality of products. The products have passed the inspections of the national , provincial and municipal quality supervision departments for many years, and successfully passed the Chinese state. These certifications includes compulsory product certification, coal mine safety certification, national industrial product production license and ISO9001 international quality management system certification. It has obtained the national certificate of use of flame retardant products and is qualified as a foreign trade operator.

FAQ

1.Are you a factory or trade company ?

We are a professional cable manufacturer with 31 years experience. The factory is located in Luoyang, Henan province, China.

2.Whether these products quality assured ?

Most of cables are certificated. Also, we have strict QC, all products are tested before delivery. Quality is assured.

3.When I want customized products, how to do?

Contacting our customers survice, we have a professional R&D team and quality inspection team that can customize products according to customer’s needs.

4.Can you send a sample for us to test?

If we have inventory, you can get 1-5meters sample for free, but freight cost need to be paid by your compony. If need a lot of samples , sample and freight cost have to be paid by your esteemed company. We will return the sample cost to you when we receiving your initial order.

5.If we want to purchase, how to pay ?

Generally we do T/T in 30% deposit before production, 70% balance against copy of B/L . Also payment terms are negotiable depending on customer’s request.

6.When you arrange delivery after we place an order ?

Normally,we will arrange delivery in 7-15 days after order , and negotiation is allowed according to your quantity.

7.After I pay, what about shipping method?

Goods can be delivered by air, by express or by sea; International Express as FEDEX, UPS, DHL, TNT; You can choose the best way as you wish.
