0.6/1kv 8mm 10mm 16mm 25mm2 35mm single 1 core copper XLPE pvc flexible electrical power cable wire
Application
Low voltage cables are indicated for the transport and distribution of low voltage electricity. Recommended for industrial
connections, service connections, internal distribution and outdoor connections. It can be used in underground networks
and permanent installations.
1. Conductor: Stranded Copper, Class 2
2. Insulation: Cross-Linked Polyethylene (XLPE)
3. Sheath:PVC
4.Armour:Unarmored Copper Cable
|
HIGH ELECTRICAL CONDUCTIVITY COPPER OR ALUMINIUM CONDUCTOR
Copper or aluminium stranded(Class 2) conductors according to lEC 60228
|
|
|
HIGH RESISTANCE PVC/XLPE INSULATION
Available with Cross-linked Polyethylene(XLPE)or Polyvinyl Chloride(PVC) insulation
|
|
|
UV RESISTANCE & FLAME RETARDANT PVC JACKET
Provided with flame retardant PVC jacket to pass flame propagation test to lEC60332-1
|
|
|
CUSTOMIZED DESIGNS
Available in Armoured/Non-armoured and Shielded/Non-shielded constructions
|
|
Cable section
|
Outer diameter
|
Approximate mass
|
Admissible current in amperes
|
Voltage drop V/A/Km cosØ=0.8
|
|
|
(mm²)
|
approx (mm)
|
(Kg/Km)
|
In the open air 30°C
|
In the ground 20°C
|
|
|
1×1.5
|
5.5
|
42
|
24
|
31
|
21
|
|
1×2.5
|
5.8
|
53
|
33
|
41
|
13
|
|
1×4
|
6.5
|
70
|
45
|
53
|
8.3
|
|
1×6
|
7.0
|
94
|
58
|
66
|
5.5
|
|
1×10
|
7.8
|
110
|
80
|
87
|
3.3
|
|
1×16
|
8.7
|
195
|
107
|
113
|
2.1
|
|
1×25
|
10.5
|
300
|
138
|
144
|
1.3
|
|
1×35
|
11.5
|
390
|
169
|
174
|
1.0
|
|
1×50
|
13.0
|
500
|
207
|
206
|
0.77
|
|
1×70
|
15.0
|
720
|
268
|
254
|
0.55
|
|
1×95
|
17.0
|
970
|
328
|
301
|
0.42
|
|
1×120
|
18.1
|
1200
|
382
|
343
|
0.35
|
|
1×150
|
20.0
|
1470
|
441
|
387
|
0.30
|
|
1×185
|
22.1
|
1830
|
506
|
434
|
0.26
|
|
1×240
|
25.0
|
2380
|
599
|
501
|
0.22
|
|
1×300
|
38.0
|
3000
|
693
|
565
|
0.19
|
|
1×400
|
31.5
|
3880
|
825
|
662
|
1.17
|
|
1×500
|
38.5
|
4860
|
946
|
749
|
0.15
|
|
1×630
|
43.0
|
6265
|
1088
|
851
|
0.14
|
