0.6/1kv 4X4 4X6 4X10 4X25 4X50 4X95 mm2 Cu Copper Conductors XLPE Insulated LSZH Halogen-Free Sheathed Xgb Power Cable

0.6/1kv 4X4 4X6 4X10 4X25 4X50 4X95 mm2 Cu Copper Conductors XLPE Insulated LSZH Halogen-Free Sheathed Xgb Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

XGB

Insulation Material

XLPE

Sheath Material

LSZH

Material Shape

Round Wire

Wire Core Material

Copper Conductor

Certification

ISO, CCC, CE, VDE

Model

Brand

Huadong

Product Name

Xgb Power Cable

Rated Voltage

0.6/1kv

Armour

Non Armoured

Size

1.5-300mm2

Color

Green

Cores

1 2 3 4 5 7 12 14 19 21 24 30 37 40 Ect

MOQ

1000m

Standards

IEC 60502 / BS 5467 Standard

Transport Package

by Wooden Drum

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

0.6/1kV 4X4 4X6 4X10 4X25 4X50 4X95 MM2 Cu Copper conductors XLPE insulated LSZH halogen-free sheathed XGB Power cable

Application:
XGB are fire retardant power cables for domestic and industrial applications with a voltage rating of 1kV. This product range is suitable for use indoor and outdoor, protected by ducts for mechanical and UV protection. They are suitable for use in public buildings including airports, hospitals and railway stations and in any environment which would be sensitive to smoke and corrosive gases in the event of a fire due to the concentration of people or the presence of valuable equipment, especially in difficult evacuation conditions

Construction:
1.1.5mm2-6mm2 solid copper wire; up 6mm2 Stranded Copper wire
2. XLPE insulation
3. FR-LSZH inner sheath
4. FR-LSZH outer sheath

Technical data:

Nominal voltage Uo/U		[V]	600 / 1000 volt
Test voltage		[V]AC	3500
Temperature range	in motion		-5°C till +90°C
	fixed		-10°C till +90°C
Operating temperature	short circuit	°C	250
Short circuit time	max.	[sec]	5
Flammability	standard		IEC 60502-1 & BS 5467

XGB Cable Dimensions

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced 20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers.We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane Cables and Other Special Use Cables.

1.what is our payment term ?

Our payment term is usually T/T 30% advanced, the balance before picking up the goods or L/C at sight.

2.what is the lead time ?

The lead time usually is 10 – 30 working days.

3.what is the package of the cable ?

The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.

4.Could we provide the free sample for customer ?

Sure, we provide the free sample for customer to checking.

Please feel free to leave your requirement, We will reply you in 12 hours.

We are China 0.6/1kv 4X4 4X6 4X10 4X25 4X50 4X95 mm2 Cu Copper Conductors XLPE Insulated LSZH Halogen-Free Sheathed Xgb Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
