0.6/1 Kv Nyrgby Low Voltage Underground Power Supply Cable

Copper conductor,PVC insulated,galvanized steel wire armor,
PVC sheathed,0.6 kV power cable
NYRGbY

Cable Structure: Conductor: [re] round solid conductor
[rm] circular stranded conductor
[Sm]Sector shape conductor
Insulation: PVC
Filler: PVC
Armour: A layers of Galvanized round steel wires with
a counter helix layer of galvanized steel tape.
Out Sheath: PVC or FR-PVC type ST1/ST2/ST8,black.
Code designation: NYRGbY
Application: For general purpose distribution in dry or wet location,best suitable for
direct burying ground.
European standards: IEC 60502-1,VDE 0271,IS 1516.1
Flame retardant according to EN 60332-1.
Indonesia standards: Conductor SNI IEC 60228,
PVC insulation SNI IEC 60502-1/
PVC sheath Grade ST1 to SNI IEC 60502-1.
Technical data: Voltage rating :Uo/U 0.6/1 kV
Test Voltage:3.5kV
Temperature Rating Maximum Operating: +70ºC
Maximum Short-Circuit:+160ºC
Minimum. Bend Radius:12×overall diameter
Certificates: CE,CCC, RoHS,KEMA and more others at request.

Our company, Tianhuan Cable Group Co., Ltd., has successfully approved LVD legislation and CPR legislation of CE certifications,as well as holding product certificates from TUV and CCC. Furthermore, we have also passed a series of management system certifications by ISO.

Our factory has 18 sets of production lines including multi-types of advanced equipment, and 30 sets of testing machinas, given by production capacity of 11 million kilometers per year. we have skillful staff with work experience over 20 years count over 80, everyone get trained professionally, that makes us can promise all product delivered 100% qualified
Copper Conductor/Multi-Core/Xple Insulated/PVC Sheath/Unarmored/Low Voltage Cable/Lab Test
We promise every wire need to be test strictly, in addition, test resistance, insulation thickness, the tension, stretch and so on. we promise all product shipping out shall be the 100% qualified.

Package way for Export can be very special, all design should be strong enough to stand long distance transportation and vibration on some level, with Shipping mark in a clear way.
Iron wood composited drum with reinforced structure or full iron drum shall be suitable for the job. we choose rightful dimension to Reels and spools, usually we give inside cover on cable roll, and out ring wood board outside evenly. Steel tape to tie up, all wooden structures have been fumigated, with steel pallet downside. Customized job more than it, we are able to do it.

1. The time you can get the quotation after the sending the inquiry
In the working time, our sales manager will send quotation to your email box within 1 or 2 hours. On the contrast, we will send you email within 12 hours. Therefore, email is needed to let us know, then we can contact with you.

2. For Sample
We can provide you the sample for free, if you want to check the cable, you can ask the sales manager.

3.Payment
Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.

4. what is the package of the cable ?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirement. …… If you have any other question, you can send us inquiry, we will reply to you as soon as possible.
