Xlpo DC Solar Cable PV Power Cable Insulated 35mm²

1.   Main Application
    These cables are designed for connecting photovoltaic system components inside and outside of buildings and equipment with high mechanical requirements and extreme weather conditions

2.   Standards
    TÜV 2PfG 1169/08.2007 (PV1-F) , EN 50618 :2014 (H1Z2Z2-K) ,IEC 62930 : 2017 .

3.   Construction:

1: Conductor: Stranded tinned copper conductor per DIN VDE 0295 and IEC 60228 Class 5.
2: Insulation: Electron beam cross-linked, halogen free and flame retardant compound.
3: Sheath: Electron beam cross-linked, halogen free and flame retardant compound, Black or Red. Other colours available on request

Electrical Properties
»Rated Voltage U 0/U:  AC: 1000V/1000V; DC: 1500V/1500V;
»Maximum Permitted DC Voltage: 1800V DC (conductor/conductor, non-earthed system, circuit not under load)
»Spark Test: 6000 V ac (8400 V dc)
»Voltage Withstand: 6500 V ac for 5 min
Thermal Properties
» Maximum Voltage: Ambient Temperature: -40ºC ºC~ +90ºC
» Maximum Temperature At Conductor: 120ºC ºC(20000h) according to IEC/EN 60216-1
» Short Circuit Temperature: 200ºC/5 sec
» Thermal Endurance Test: According to EN 60216-2 (temperature index +120° °C)
» High Temperature Pressure Test: According to EN 60811-3-1
» Damp-Heat Resistance: According to EN 60068-2-78 with 85% humidity
Mechanical Properties
» Minimum Bending Radius: 4×OD (fixed), 5×OD (flexing)
» Dynamic Penetration: According to 2 PfG 1169/08.2007 Annex F
» Notch Propagation: According to 2 PfG 1169/08.2007 Annex G
» Tensile Strength and Elongation Of Insulation And Jacket: According to EN 60811
» Anticipated Period Of Use: 25 years
Chemical Properties
» Ozone Resistance: According to EN 50396 part 8.1.3 Method B
» Weathering-UV Resistance: According to HD 605/A1
» Ammoniac resistant » Very good resistance to oils and chemicals
» High wear and robust, abrasion resistant
» Acid & Alkaline Resistance: According to EN 60811-2-1 (Oxal acid and sodium hydroxide)

EC directives
» The cables are conform to the EC directives CE 2006/95/EC (Low voltage directive) and RoHS 2002/95/EC (Restriction of Hazardous Substances)
Fire Performance
» Flame retardant according to EN 50265-2-1, IEC 60332-1, VDE 0482-332-1-2, DIN EN 60332-1-2
» Low smoke emission according to IEC 61034, EN 50268
» Halogen free according to EN 50267-2-1, IEC 60754-1
» Low corrosively of gases according to EN 50267-2-2, IEC 60754-2

Dimensions according to EN 50618

Current Carrying Capacity

Conversion Factor for Deviating Temperatures

Reduction factor for accumulation according to IEC 60364-5-52, Table B.52-17

Packaging Mode 1 :Coils On Wooden Case,Packing length about 200 Coils(100Meter/Colis)
Packaging Mode 2 :Coils On Wooden Tray Cover Waterproof Film,Packing length about 300 Coils(100Meter/Colis)

      Xinfeng Cable Co., Ltd. is a research and development, production, sales in one of the well-known wire and cable enterprises, with a complete and scientific quality management system, advanced technical team support, strong sales and after-sales service.
      Henan Xinfeng Cable Co., LTD., founded in 1996, with a registered capital of 210 million CNY, covers a total area of 50,000 square meters, the existing staff of 586 people, including a variety of technical personnel more than 80 people, with a university degree 60 people, the company has the current domestic advanced production equipment and testing equipment, including more than 200 sets of advanced cable production equipment. And spend tens of millions to purchase the most complete cable testing equipment.
      In 2012, the company took the lead in the cable industry through the ISO9001 international quality system certification, ISO14001 occupational safety and health certification system, 18001 environmental management certification, national CCC compulsory certification and other qualifications, and through the European safety product CE certification, European environmental protection ROSH certification, SGS environmental protection product testing certification. In 20 years of development, it has formed an annual production capacity of 1.5 billion CNY for overhead insulated wires, high and low voltage cables, BV cables and other products, and constantly improve and expand the research and development and production field of cable products.
      At present, the company is mainly engaged in the system design, development, manufacturing, marketing and service of more than 1000 kinds of cables in four categories: overhead wire, power cable, electrical equipment wire and cable, and special cable. Products are widely used in power, water conservancy, railway, transportation, new energy, petroleum and petrochemical, national defense, construction and urban infrastructure and other fields.
      The company is headquartered in Zhengzhou, and has set up 8 branches in Beijing, Wuhan, Xi ‘an, Hefei, etc., responsible for the sales and after-sales work in and around the region. In 2013, the group wholly established Henan JinFar East Cable Co., LTD., responsible for the international market sales and expansion business, products are exported to the Americas, Africa, Australia, Europe and other 38 countries and regions, products by foreign customers praise.
      With the continuous expansion of product share, Xinfeng cable products have also been widely recognized and praised by the majority of users, The company has successively won the industry “National quality integrity enterprise”, “China Famous products”, “Henan famous brand products”, 2013-2015 successively won the Henan Provincial Bureau of Industry and Commerce “contract-abiding and trustworthy enterprise”, “quality, service, credit AAA enterprise”, “National product quality supervision and sampling inspection qualified enterprise” and other honors.

1.High Quality Raw Materials:Purity Up To 99.97% Oxygen-Free Copper.Strong current capacity, Long Service life, High safety.

2.Quality Control:In Strict Accordance With IEC 60227 Standards.The factory has well-equipped quality control room,can complete the inspection of all major electrical parameters.

3.OME Service:Support printing customization, packaging customization, help customers design own Brand, and flyers.
Part Clent Brand Display:
4.Experienced Team:Our experienced production and sales teams can respond to a wide variety of projects, quickly respond to customer needs, and are able to provide type test reports for most major products.

Q:What factors should be considered when selecting a power cable?
A:Factors include voltage rating, current carrying capacity, environmental conditions (temperature, moisture, chemicals), mechanical stresses (such as impact or vibration), installation requirements, and regulatory standards.Our sales team can assist in selecting the appropriate cable based on these factors.

Q:What types of power cables do you offer?
A:We offer a wide range of power cables including low voltage (voltages up to 1000V.), medium voltage (1000V to 35 kV.). We also provide specialty cables such as fire-resistant, armored, and flexible cables to meet various customer needs.

Q:What are the benefits of buying power cables from your company?
A:We provide high-quality cables manufactured to international standards.Our cables are durable, reliable, and designed to meet specific application requirements.We offer competitive pricing and flexible delivery options to meet project timelines.Our experienced team provides technical support and advice to ensure the right cable selection for your project.

Q:Can I request samples of your power cables before making a purchase?
A:Yes, we can provide samples of our power cables for evaluation purposes. Sample availability may vary depending on the type and specifications of the cable. Contact our sales team to request samples and discuss shipping arrangements.

Q:Do you provide documentation and support for product certifications required for government tender or public sector projects?
A:Yes, we offer documentation and support to assist with product certifications required for government or public sector projects. Our team can help navigate regulatory requirements, provide compliance documentation, and ensure that our power cables meet specific project specifications and standards.
