XLPE Insulated Aerial Bundle Overhead Aluminum Cable ABC Cable 2X25mm2

XLPE Insulated Aerial Bundle Overhead Aluminum Cable ABC Cable 2X25mm2 image

Get Latest Price Request a quote

Product Details

Model NO.

Insulated Cable

Conductor Material

Aluminum

Sheath Material

PVC , XLPE

Insulation Material

PVC , XLPE

Material Shape

Round Wire

Certification

ISO9001, CCC, SGS

Brand

Kingyear

Voltage

Low, Medium, High

Core

Single , Duplex , Triplex , Qundruplex

Color

Black, Grey, Red

Standard

IEC, BS, DIN, ASTM, NFC

Rated Voltage

0.6/1kv, 11kv, 22kv, 35kv

Advantage

High Quality, Competitive Price

OEM

Yes

Delivery Time

15-25days

Transport Package

Wooden Drum, Roll, as Request

Specification

1.5-400mm2

Trademark

Kingyear

Origin

Henan, China

HS Code

854449210

Production Capacity

1000km/Month

Product Description

XLPE Insulated Aerial Bundle Overhead Aluminum Cable ABC Cable 2x25mm2

Applications

The product is à new type of aerial cable for power transmitting. It is extensively used in overhead power transmission line. It improves the safety and rellance of electrified wire netting.

standard

GB12527-91,IEC502, BS7870-5,NFC33-209
Other standards such as BS,DIN,ASTM and ICEA upon request

specification

Phase	Phase		Phase			Approx.Overall Diameter	Max. D.C. Resistance of Conductor at 20ºC
AAC+XLPE	Compact Conductor		XLPE Insulation
No. X Normal Cross Section of Cores	No.of Al Wires	Overall Diameter	Normal Thickness	Min.	Diameter
No. X mm2	–	mm	mm	mm	mm	mm	ohm/km
1 X 10	7	4.05	1	0.8	6.05	6.05	3.08
1 X 16	7	4.8	1.2	0.98	7.2	7.2	1.91
1 X 25	7	6	1.2	0.98	8.4	8.4	1.2
1 X 35	7	7	1.4	1.16	9.8	9.8	0.868
1 X 50	7	8.3	1.4	1.16	11.1	11.1	0.641
1 X 70	19	9.8	1.4	1.16	12.6	12.6	0.443
1 X 95	19	11.6	1.6	1.34	14.8	14.8	0.32
1 X 120	19	13	1.6	1.34	16.2	16.2	0.253
1 X 150	19	14.6	1.8	1.52	18.2	18.2	0.206
1 X 185	36	16.2	2	1.7	20.2	20.2	0.164
1 X 240	36	18.4	2.2	1.88	22.8	22.8	0.125

Duplex Service Drop-Aluminum Conductor

Code Name	Phase Conductor				Bare Natural		Weight			Ampacity
	Size&No. of Wires	Insulation Thickness	Nominal Diameter		Size&No.of Wire	Rated Strength	XLPE	Al	Total	Ampacity
	Size&No. of Wires	Insulation Thickness	Bare	OD	Size&No.of Wire	Rated Strength	XLPE	Al	Total
		mm	mm	mm		kg	kg/km	kg/km	kg/km	A
AAC
Pekingese	6-Solid	1.14	4.1	6.4	6-7	255	20.8	72.9	94	78
Collie	6-7	1.14	4.6	6.9	6-7	255	23.8	72.9	97	78
Cocker	6-7	1.52	4.6	7.7	6-7	255	32.7	72.9	106	78
Dachshund	4-Solid	1.14	5.2	7.5	6-7	400	26.8	114.6	141	103
Spaniel	4-7	1.14	5.9	8.2	6-7	400	29.8	116.1	146	103
Doberman	2-7	1.14	7.4	9.7	2-7	612	38.7	184.5	223	136
Basset	1/0-7	1.52	9.3	12.4	1/0-7	903	64.0	294.7	359	182
AAAC
Chihuahua	6-Solid	1.14	4.1	6.4	6-7	499	20.8	72.9	94	78
Vizsla	6-7	1.14	4.6	6.9	6-7	499	23.8	72.9	97	78
Harrier	4-Solid	1.14	5.2	7.5	4-7	798	26.8	116.1	143	103
Afghan	1/0-7	1.52	9.3	12.4	1/0-7	2023	64.0	296.1	360	182
Heeler	1/0-19	1.52	9.4	12.5	1/0-7	2023	64.0	296.1	360	182
ACSR
Setter	6-Solid	1.14	4.1	6.4	6/6/01	540	20.8	72.9	94	78
Shepherd	6-7	1.14	4.6	6.9	6/6/01	540	23.8	72.9	97	78
Eskimo	4-Solid	1.14	5.2	7.5	4/6/01	844	26.8	114.6	141	103
Bloodhound	1/0-7	1.52	9.3	12.4	1/0-6/1	1987	64.0	294.7	359	182
Bull	1/0-19	1.52	9.4	12.5	1/0-6/1	1987	64.0	294.7	359	182

We are China XLPE Insulated Aerial Bundle Overhead Aluminum Cable ABC Cable 2X25mm2 manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
