Type G Soow 600V UL cUL Portable Cable 3core 10AWG

Type G Soow 600V UL cUL Portable Cable 3core 10AWG image

Get Latest Price Request a quote

Product Details

Model NO.

SOOW SJOOW

Conductor Material

Flexible Stranded Copper

Sheath Material

CPE, Sun Resistance, Oil /Water Resistance

Insulation Material

Epr EPDM

Material Shape

Round Wire

Range of Application

Welding Machine

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

QIFAN

Standard

UL ASTM VDE

Color

Black Red Yellow

Working Temperture

90 ºC or 105ºC

Rated Voltage

300V 600V

Transport Package

Roll Drum

Specification

4AWG-1000MCM 16-800mm2

Trademark

QIFAN

Origin

China

HS Code

8544492100

Production Capacity

50000km/Month

Product Description

Multi-Conductor Type SOOW, 600 Volt, UL /CUL Portable Cable 18AWG – 10AWG

APPLICATION

TYPE SOOW Cable is for use in heavy-duty industrial applications where flexibility and durability is required. SOOW is designed for extra hard usage on industrial equipment, heavy tools, motor and welding leads, power extensions, portable machinery, sound equipment, portable stage lights, marine dockside power and mining applications. Constructed of color-coded synthetic oil, ozone and water resistant rubber (EPDM) insulation and an oil resistant thermoset chlorinated polyethylene (CPE) jacket, SOOW is rated for indoor/outdoor use.

SOOW flexible rubber cords carry a 600 volt rating. They are also manufactured as a 300 volt rated Junior Service cord designated as SJOOW. Using the key, a SJOOW cord is a 300 volt (junior service) elastomer plastic oil resistant inner and outer jacket portable cord.

Applications

Portable tools
Industrial and processing equipment
Construction equipment
Cranes and hoists
Track systems
Battery chargers
Portable appliances
Small motors and associated machinery
Electrical equipment exposed to oils, solvents, flame, or moisture

STANDARDS & REFERENCES

Type SOOW Cords/Cable meets or exceeds the applicable requirements of the following standards and

specifications:

UL Standard 62 for Flexible Cords

CSA Standard 22.2 No. 49 for Flexible Cords

MSHA flame resistance for mining applications

NEC Article 400

RoHS Compliant

SOOW offers:

    • Excellent resistance to oils, acids, chemicals, water, ozone, extreme

      temperatures, cuts, tears and abrasion

    • Sunlight resistant

    • Flame retardant

    • Indoor/outdoor rated

    • Highly flexible

    • Maximum continuous conductor temperature: 90°C DRY

CONSTRUCTION

Conductors: Bare, annealed copper per ASTM B-3 Flexible, bunch-stranded per UL-62

Separator: A paper tape is applied between the conductor and insulation to facilitate stripping.

Insulation: Color coded synthetic rubber (EPDM) oil and water resistant per UL-62

Jacket: Black Chlorinated Polyethylene (CPE)

Cabling: Conductors are assembled round with fillers as needed.

Temperature Range: -40°C to +90°C

Voltage Rating: 600 Volts for SOOW,300 Volts for SJOOW

Conductor Size (AWG)	Conductor Stranding			Nominal Insulation Thickness	Nominal Jacket Thickness	Nominal Overall Diameter (in)	Weight	Ampacity
Conductor Size (AWG)	n	/	AWG/inch	mil	mil	in	lbs/1000ft	A
2*18AWG	16	/	30	30	60	0.33	70	10
3*18AWG	16	/	30	30	60	0.35	80	10
4*18AWG	16	/	30	30	60	0.37	96	7
2*16AWG	26	/	30	30	60	0.36	86	13
3*16AWG	26	/	30	30	60	0.37	99	13
4*16AWG	26	/	30	30	60	0.41	119	10
2*14AWG	41	/	30	45	80	0.49	155	18
3*14AWG	41	/	30	45	80	0.51	179	18
4*14AWG	41	/	30	45	80	0.56	215	15
2*12AWG	65	/	30	45	95	0.56	206	25
3*12AWG	65	/	30	45	95	0.58	239	25
4*12AWG	65	/	30	45	95	0.63	290	20
2*10AWG	104	/	30	45	95	0.62	266	30
3*10AWG	104	/	30	45	95	0.66	316	30
4*10AWG	104	/	30	45	95	0.72	385	25
3*8AWG	133	/	29	60	110	0.83	505	40
4*8AWG	133	/	29	60	125	0.93	646	35
5*8AWG	133	/	29	60	125	0.93	684	35
3*6AWG	133	/	27	60	125	0.95	694	55
4*6AWG	133	/	27	60	140	1.07	885	45
5*6AWG	133	/	27	60	140	1.07	946	45
3*4AWG	133	/	0.0177	60	140	1.09	952	70
4*4AWG	133	/	0.0177	60	155	1.22	1210	60
5*4AWG	133	/	0.0177	60	155	1.22	1304	60
3*2AWG	133	/	0.0223	60	155	1.26	1344	95
4*2AWG	133	/	0.0223	60	170	1.41	1705	80
5*2AWG	133	/	0.0223	60	170	1.41	1853	80

We are China Type G Soow 600V UL cUL Portable Cable 3core 10AWG manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
