Single or Multicore Xlpo 2pfg 1169 08.2007 Solar Cable 1X6

Single or Multicore Xlpo 2pfg 1169 08.2007 Solar Cable 1X6 image

Get Latest Price Request a quote

Product Details

Model NO.

H1Z2Z2-K

Conductor

Tinned Copper Core

Insulation

Xlpo

Sheath

Xlpo

Rating Voltage

600/1000V,1000/1800V DC

Max Temperature at Conductor

120°c

Transport Package

Coils, Rolls or Drums

Specification

As per the customer request

Trademark

GUOWANG

Origin

China

HS Code

8544492100

Production Capacity

5000000/Week

Product Description

flexible tinned copper Single core H1Z2Z2-K solar cable

For long-time permissible operation, temperture of conductor shall not exceed 70°C.

Application:
Application: H1Z2Z2-K European standard solar cable intended for the interconnection within photovoltaic systems such as solar panel arrays. Suitable for fixed installations, internal and external, within conduit or systems, but not direct burial
applications.

Standards:

EN 50618,TÜV 2 PfG 1169/082007,EN 50288-3-7 EN 60068-2-78.

Flame retardant according to IEC/EN 60332-1-2
Low Smoke Zero Halogen according to IEC/EN 60754-1/2.IEC/EN61034-1/2

UV Resistant according to HD 605 S2

Characteristics Conductor: Class 5 flexible tinned copper conductor

Insulation: Halogen-free cross-linked compound

Sheath: Halogen-free cross-linked. flame retardant compound

Rated Voltage Uo/U:

AC:1000/1000V DC: 1500/1500V

Maximum Voltage (Umax):

1800V

Temperature range:

-40ºCto+90ºC

Minimum Bending Radius:

Fixed: 4 x overall diameter

Flexed: 5 x overall diameter

Cable Colour: Black

Packaging: 100m Rolls, 500m Rolls

Part No.	No. of Core	Nominal Cross Section(mm2)	Nominal Overall diameter(mm)
H1Z2Z2-K 10025	1	2.5	4.9
H1Z2Z2-K 10040	1	4	5.4
H1Z2Z2-K 10060	1	6	5.9
H1Z2Z2-K 10100	1	10	6.9
H1Z2Z2-K 10160	1	16	8.0
H1Z2Z2-K 10250	1	25	10.3
H1Z2Z2-K 10350	1	35	11.8
H1Z2Z2-K 10500	1	50	13.5
H1Z2Z2-K 10700	1	70	16.0
H1Z2Z2-K 10950	1	95	17.8
H1Z2Z2-K 11200	1	120	19.8
H1Z2Z2-K 11500	1	150	21.1
H1Z2Z2-K 11850	1	185	24.4
H1Z2Z2-K 12400	1	240	27.1
