Quadruplex Service Drop / ACSR (ABC Cable) 2X95+95sqmm

Quadruplex Service Drop / ACSR (ABC Cable) 2X95+95sqmm image

Get Latest Price Request a quote

Product Details

Conductor Material

Aluminum

Sheath Material

Crosslinking

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

Overhead

Certification

ISO9001, CE, CCC, VDE, Soncap

Brand

Jinshui

Certificate

ISO14001,ISO18001

Neutral

AAC, AAC, or ACSR

Experience

32 Years Produce

Transport Package

Wooden Drums or Coil

Specification

SGS, CE

Trademark

JINSHUI

Origin

China

HS Code

8544492100

Production Capacity

10000km/Month

Product Description

600V aluminium ABC CAAI cable with XLPE insulation , aerial bundled cable:

Core number : Single, Duplex, Triplex, Quadplex and above

Application:

It is preferred to use of service drop (ABC cables) instead of uninsulated conductors

at low voltage networks. service drop (ABC cables)are especially used at areas

where the cost of underground networks is expensive and also

for electrification of rural areas like villages.

Voltage

Rated voltage U0 / U = 0.6 /1 kV

VAC test voltage 5 kV

Technical Data

Maximum operating temperature 90 degree

Maximum short-circuit temperature 250 degree. Service drop( ABC cables) are especially used at areas where the cost of underground networks is expensive and also for electrification of rural areas like villages.

Phase	Phase		Phase			Approx.Overall Diameter	Max. D.C. Resistance of Conductor at 20 Centigrade
AAC+UV-XLPE	Compact Conductor		UV-XLPE Insulation
No.X Normal Cross Section of Cores	No.of Al Wires	Overall Diameter	Normal Thickness	Min.	Diameter
No. X mm 2	–	mm	mm	mm	mm	mm	ohm/km
1 X 10	7	4.05	1.0	0.8	6.05	6.05	3.08
1 X 16	7	4.8	1.2	0.98	7.2	7.20	1.91
1 X 25	7	6	1.2	0.98	8.4	8.40	1.20
1 X 35	7	7.0	1.4	1.16	9.8	9.80	0.868
1 X 50	7	8.3	1.4	1.16	11.1	11.10	0.641
1 X 70	19	9.8	1.4	1.16	12.6	12.60	0.443
1 X 95	19	11.6	1.6	1.34	14.8	14.80	0.320
1 X 120	19	13	1.6	1.34	16.2	16.20	0.253
1 X 150	19	14.6	1.8	1.52	18.2	18.20	0.206
1 X 185	36	16.2	2.0	1.70	20.2	20.20	0.164
1 X 240	36	18.4	2.2	1.88	22.8	22.80	0.125
2 X 10	7	4.05	1.0	0.8	6.05	12.10	3.08
2 X 16	7	4.8	1.2	0.98	7.2	14.40	1.91
2 X 25	7	6	1.2	0.98	8.4	16.80	1.20
2 X 35	7	7.0	1.4	1.16	9.8	19.60	0.868
2 X 50	7	8.3	1.4	1.16	11.1	22.20	0.641
2 X 70	19	9.8	1.4	1.16	12.6	25.20	0.443
2 X 95	19	11.6	1.6	1.34	14.8	29.60	0.320
2 X 120	19	13	1.6	1.34	16.2	32.40	0.253
2 X 150	19	14.6	1.8	1.52	18.2	36.40	0.206
2 X 185	36	16.2	2.0	1.70	20.2	40.40	0.164
2 X 240	36	18.4	2.2	1.88	22.8	45.60	0.125
3 X 10	7	4.05	1.0	0.8	6.05	13.07	3.08
3 X 16	7	4.8	1.2	0.98	7.2	15.55	1.91
3 X 25	7	6	1.2	0.98	8.4	18.14	1.20
3 X 35	7	7.0	1.4	1.16	9.8	21.17	0.868
3 X 50	7	8.3	1.4	1.16	11.1	23.98	0.641
3 X 70	19	9.8	1.4	1.16	12.6	27.22	0.443
3 X 95	19	11.6	1.6	1.34	14.8	31.97	0.320
3 X 120	19	13	1.6	1.34	16.2	34.99	0.253
3 X 150	19	14.6	1.8	1.52	18.2	39.31	0.206
3 X 185	36	16.2	2.0	1.70	20.2	43.63	0.164
3 X 240	36	18.4	2.2	1.88	22.8	49.25	0.125
4 X 10	7	4.05	1.0	0.8	6.05	14.64	3.08
4 X 16	7	4.8	1.2	0.98	7.2	17.42	1.91
4 X 25	7	6	1.2	0.98	8.4	20.33	1.20
4 X 35	7	7.0	1.4	1.16	9.8	23.72	0.868
4 X 50	7	8.3	1.4	1.16	11.1	26.86	0.641
4 X 70	19	9.8	1.4	1.16	12.6	30.49	0.443
4 X 95	19	11.6	1.6	1.34	14.8	35.82	0.320
4 X 120	19	13	1.6	1.34	16.2	39.20	0.253
4 X 150	19	14.6	1.8	1.52	18.2	44.04	0.206
4 X 185	36	16.2	2.0	1.70	20.2	48.88	0.164
4 X 240	36	18.4	2.2	1.88	22.8	55.18	0.125

Packaging & Shipping

We are China Quadruplex Service Drop / ACSR (ABC Cable) 2X95+95sqmm manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
