POLY ACSR 266.8MCM Hackberry LLDPE OR XLPE COVERED LINE WIRE CONDUCTOR

POLY ACSR 266.8MCM Hackberry LLDPE OR XLPE COVERED LINE WIRE CONDUCTOR image

Get Latest Price Request a quote

Product Details

Model NO.

POLY ACSR

Current

AC Cable

Insulation Material

Sheath Material

N/A

Material Shape

Round Wire

Wire Core Material

ACSR

Certification

ISO, CCC, CE

Model

Poly ACSR

Brand

Grandcable

Transport Package

Fumigated Drums

Trademark

Grandcable

Origin

Jiangsu, China

HS Code

8544492100

Production Capacity

78000 Km Per Year

Product Description

POLY ALL ALUMINUM CONDUCTORS STEEL REINFORCED (POLY ACSR)

PE Insulated 75°C,600 Volts
Stranded sizes AWG #6 to 266.8MCM

Specifications

Grand Cable Type Poly ACSR meets and exceeds applicable ASTM B 232 specification & ANSI/ICEA-S-70-547 Specification.

Application

Grand Cable Type Poly ACSR conductors are primarily used in overhead distribution lines. Installed on insulators, otherwise treated as bare conductor.

Application

Grand Cable Type Poly ACSR conductors are concentrically stranded according to ASTM B 232. Covered with weather resistant black polyethylene compound.

Dimenison Characteristics:

Code Name	Size	Stranding No. /mm		Insulation Thickness	Approx. Over-all Diameter	Rated Strength	Approx. Cable Weight	Allowable Ampacity+ (Amps)++


	AWG/MCM	Al.	Steel.	mm	mm	kg	kg/km	A
Walnut	6	6/1.68	1/1.68	0.76	6.56	513.02	70.37	105
Butternut	4	6/2.12	1/2.12		7.88	801.51	107.36	135
Hickory	4	7/1.96	1/2.61		8.01	1016.97	126.4	135
Pignut	2	6/2.67	1/2.61	1.14	10.30	1228.35	175.69	180
Beech	2	7/2.47	1/3.30		10.46	1568.55	206.63	180
Chestnut	1	6/3.00	1/3.00		11.28	1529.99	215.79	210
Almond	1/0	6/3.37	1/3.37	1.52	13.16	1887.43	282.97	235
Pecan	2/0	6/3.78	1/3.78		14.39	2288.41	348.16	270
Filbert	3/0	6/4.25	1/4.25		15.80	2852.69	431.32	305
Buckeye	4/0	6/4.77	1/4.77		17.36	3598.41	533.82	345
Hackberry	266.8	18/3.09	1/3.09		18.50	2964.73	532.34	435

+ Ampacity ratings based on 75°C conductor temperature25°C ambient temperature elevation – sea level.

++ Emissivity 0.91 coefficient of aborption 0.95. Thermal resistivity of covering -375^OC – CM /Watt-CM. Wind speed 2ft/sec. In sun.

Testing Facilities

Packaging Photos

Workshop Views

About us:

Jiangsu Grand Cable Co., Ltd. was founded in 2002 with a registered capital of 308.88 million CNY(equivalent to 44.13 million USD). The company is located at Section B, Guanlin Industrial ConcentratedArea, Yixing, Wuxi City, Jiangsu 214251, P.R. China, covering an area of 130,000 squaremeters .It owns total assets of 100 million CNY and more than 500 staff members. The annualproduction capacity reaches 2.5 billion CNY .It is one of key enterprises of China Wire & Cable Industry, the National High-Tech Enterprises, the Innovation and Development Pilot Enterprises of Jiangsu Province, the Private Technology Enterprises in Jiangsu Province, keeping Contract and Credit Enterprises and AAA-Grade Credit Enterprise. We have passed ISO9001 Quality System,ISO14001 Environment Management System Certificate and OHSAS 18001 Occupational Health and Safety Management System Certificate.

With more than 300 sets of first-class domestic and imported manufacture and test equipment,Grand Cable can manufacture ten thousand specifications, including Bare Conductors, Earthing Materials, Electric Cables, Solar Cables, Overhead/Aerial Cables, Control Cables, Instrumentation Cables, Power Cables(LV/MV/EHV), Special Cables.

FAQ:

Q: How long does it take get my inquiry replied?

A: Mostly the inquiry will be replied within 12 hours. And the quote will be sent to you in 1-3 days. It depends on the technical parameters and requirements of the cable. We will give you a reasonable and accurate quote.

Q: Can I get samples before placing the order?

A: You will get a sample for free if we have the storage of that cable.

Q: What’s the MOQ of your product?

A: The MOQ of our most product is 1000 meters. But if there’s any exceptional situation, we can make some negotiations.

Fore More Information, Please do feel free to contact us!

We are China POLY ACSR 266.8MCM Hackberry LLDPE OR XLPE COVERED LINE WIRE CONDUCTOR manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
