Low and Medium Voltage Tinned Copper Conductor Solar Cable with CE
Low and Medium Voltage Tinned Copper Conductor Solar Cable with CE image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
Our products are produced according to the standards of GB, IEC, BS, DIN, ASTM, JIS, NF, AS/NZS, CSA and so on. Meanwhile we can produce based on customers’ requirements and specifications. The company has passed ISO9001 2008 quality certification, CCC China Compulsory Certification, National Electrical Product Safety Certification, State Construction and ProjectCommitee Recommended Manufacturer of the Transformation of Urban and Rural Power Grid Construction.
AC 1000V PV1-F CU/XLPO/XLPO Flexible Tinned Copper Solar Power Cable H1Z2Z2-K Cable
|
Product Name
|
Solar Cables
|
|
Brand Name
|
Electra Cables
|
|
Model Number
|
H1Z2Z2-K 16mm²
|
|
Conductor
|
Copper
|
|
Application
|
The interconnection within photovoltaic systems
|
|
Temperature range
|
-40°C to +90°C
|
Application:
Application: H1Z2Z2-K European standard solar cable intended for the interconnection within photovoltaic systems such as solar panel arrays. Suitable for fixed installations, internal and external, within conduit or systems, but not direct burial
applications.
Low Smoke Zero Halogen according to IEC/EN 60754-1/2.IEC/EN61034-1/2
|
Part No.
|
No. of Core
|
Nominal Cross Section(mm2)
|
Nominal Overall diameter(mm)
|
Tensile Strength in Operation
|
Approx Mass (kg/km)
|
|
H1Z2Z2-K 10025
|
1
|
2.5
|
4.9
|
37
|
40
|
|
H1Z2Z2-K 10040
|
1
|
4
|
5.4
|
60
|
56
|
|
H1Z2Z2-K 10060
|
1
|
6
|
5.9
|
90
|
73
|
|
H1Z2Z2-K 10100
|
1
|
10
|
6.9
|
150
|
115
|
|
H1Z2Z2-K 10160
|
1
|
16
|
8.0
|
240
|
170
|
|
H1Z2Z2-K 10250
|
1
|
25
|
10.3
|
375
|
270
|
|
H1Z2Z2-K 10350
|
1
|
35
|
11.8
|
525
|
365
|
|
H1Z2Z2-K 10500
|
1
|
50
|
13.5
|
750
|
508
|
|
H1Z2Z2-K 10700
|
1
|
70
|
16.0
|
1050
|
729
|
|
H1Z2Z2-K 10950
|
1
|
95
|
17.8
|
1350
|
923
|
|
H1Z2Z2-K 11200
|
1
|
120
|
19.8
|
1800
|
1178
|
|
H1Z2Z2-K 11500
|
1
|
150
|
21.1
|
2250
|
1460
|
|
H1Z2Z2-K 11850
|
1
|
185
|
24.4
|
2775
|
1777
|
|
H1Z2Z2-K 12400
|
1
|
240
|
27.1
|
3600
|
2252
|
