LAN Cable CAT6 SFTP Braiding Outdoor Indoor Cable SFTP Good Quality

LAN Cable CAT6 SFTP Braiding Outdoor Indoor Cable SFTP Good Quality image

Get Latest Price Request a quote

Product Details

Model NO.

CAT6 SFTP

Cover Material

PVC

Type

Network Cable

Material Shape

Round Wire

Conductor Type

Solid

Wire Core Material

Bare Copper Wire

Certification

CE, ISO, RoHS, CCC

Model

Network Cable

Brand

Qinshan

Operating Temperature

-15ºC+70ºC

Jacket Color

Grey,Blue etc

Type Name

CAT6 SFTP

Outdoor Condition

Weather Proof

Voltage Rating

300/300V

Transport Package

Plastic

Specification

0.51 0.57mm2

Trademark

QINSHAN

Origin

China

HS Code

8544492100

Production Capacity

6000000meters/Year

Packaging & Delivery

Package Size

10.00cm * 10.00cm * 5.00cm

Package Gross Weight

0.500kg

Product Description

LAN Cable CAT6 SFTP CCA/CCAG/CCAM AL foil and braiding Outdoor indoor cable SFTP good quality

Standard:ANSI/TIE/EIA-568B/ISO/IEC11801

Construction:

1.Conductor: Solid copper wire conductor24AWG(0.51mm)for Cat5e23AWG(0.57mm)for Cat6

2.Insulation:PE(Polyethylene)

3.Lay-up:Two cores twisted in pair
4.Insulation color marking
1.pair:blue white with blue line
2.pair:orange white with orange line
3.pair:green white with green line
4.pair:brown white with brown line
5.Sheath:PVC(Polyvinyl Chloride)or LSOH
6.Sheath Color:Blue/Red/Black/Yellow/Grey

Characteristic:

1.Temperature Rating:-15C up to +70C

2.Voltage Rating:300/300V

3.Max.Tensile Strength:100N

4.Impedance:100±152

5.Min inner bending radius:4 x overall diameter

6.Behaviour in fire:Flame retardant to IEC60332-1

Application:

Computer network cables are used in data transmissionsystems,like home,school,shoping building public building,government network system

100BASE-T4/100BASE-TX/100VG-ANYLAN

1000BASE-T(Gigabit Ethernet);155/622Mbps ATM

Specification:

TYPE NO.	Conductor AWG	Conductor diameter	Insulation diameter	Max.outer diameter	Unshied& Shied	Unbraid&Braid		Sheath matenal
Ref.	AWG	mm	mm	mm
CAT5e UTP	4X2X24AWG	4X2X0.51mm	0.9 PE	5.1	Unshied	Unbraid		PVC or LSOH
CAT5e FTP	4X2X24AWG	4X2X0.51mm	1.1 PE	6.2	Shied	Unbraid		PVC or LSOH
CAT5e SFTP	4X2X24AWG	4X2X0.51mm	1.1 PE	6.6	Shied	Braid		PVC or LSOH
CAT6 UTP	4X2X23AWG	4X2X0.57mm	1.0 PE	6.5	Unshied	Unbraid		PVC or LSOH
CAT6 FTP	4X2X23AWG	4X2X0.57mm	1.3 PE	7.5	Shied	Unbraid		PVC or LSOH
CAT6 SFTP	4X2X23AWG	4X2X0 57mm	1.3 PE	7.8	Shied	Braid		PVC or LSOH
Electrical Characteristics CAT6 UTP/FTPISFTP
Frequency	lmpedance	Retur Loss	Attenuation	Next	PS-Next	Elfext	PS-Elfext
MHz	ohm	Db≥	≤Db/100m	≥Db/100m	≥Db/100m	≥Db/100m	≥Db/100m
1	100±15	20.0	2.0	74.3	72.3	67.8	64.8
4	100±15	23.0	3.8	65.3	63.3	55.8	52 7
10	100±15	25.0	6.0	59.3	57.3	47.8	44 6
16	100±15	25.0	7.6	56.2	54.3	43.7	40.7
20	100±15	25.0	8.5	54.8	52.8	41.8	38.8
31.2	100±15	24.0	10.7	51.9	49.9	37.9	34 9
62.5	100±15	22.0	15.4	47.4	45.4	31.9	28 9
100	100±15	20.0	19.8	44.3	42.3	27.8	24.8
155	100±15	19.0	25.2	41.5	39.5	23.9	20.9
200	100±15	18.0	29.0	39.8	37.8	21.8	18.8
250	100±15	17.0	32.8	38.3	36.3	19.8	16.8

We are China LAN Cable CAT6 SFTP Braiding Outdoor Indoor Cable SFTP Good Quality manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
