Hot Sale PVC 4mm CCA Wire Twisted Pair Wire Red and White Rvs Wire
Hot Sale PVC 4mm CCA Wire Twisted Pair Wire Red and White Rvs Wire image
Get Latest Price Request a quote
You May Like
Product Details
Packaging & Delivery
Product Description
Hot sale PVC 4mm CCA Wire Twisted pair wire Red and White RVS wire
RVS cable, twist multiple strands of cord, is also called twisted pair, or coloured thread.Applicable to household lighting,electrical appliances, instruments, broadcasting and audio connection control. Fire control wire, connected with the power amplifier and audio equipment, broadcasting system transmission by the power amplifier amplification processing of audio signals.
Construction :
1.Conductor : Stranded Copper Wire or CCA Wire
2.Insulation : PVC (Polyvinyl Chloride)
3.Color Available:
Red&Black , Red&Yellow,Red&Blue,Red&White ,Yellow&Green
Standard:
IEC60227&BS &JB8734
Technial:
Rated Voltage:300V/500V
Rated Temperature:70°C
Application:
Twisted pair wire with good flexibility and good tension that is used for lighting ,small electric instrument ,mobile lower power household appliance ,broadcast and audio equipment.
Specification Parameter :
| No.of cores x Nominal section area | Nominal Construction of conductor | Nominal Insulation thickness |
Nominal Overall diameter |
Min.Resistance of Insulation at 70ºC |
Max.Resistance of conductor at 20ºC |
| No.X mm² | No.X mm | mm | mm | (Ω/km) | <=(Ω/km) |
| Twisted Pair Wire 300/500V | |||||
| 2 x 0,5 | 2x 28 / 0,15 | 0,5 | 2,9 | 0,012 | 39,0 |
| 2 x 0,75 | 2x 42 / 0,15 | 0,6 | 3,1 | 0,011 | 26,0 |
| 2 x 1,0 | 2x 32 / 0,20 | 0,6 | 3,5 | 0,010 | 19,5 |
| 2 x 1,5 | 2×48 / 0,20 | 0,7 | 3,8 | 0,010 | 13,3 |
| 2 x 2,5 | 2×49 / 0,25 | 0,8 | 4,1 | 0,009 | 7,98 |
| 2 x 4 | 2×56/ 0,30 | 0,8 | 4,6 | 0,007 | 4,95 |
| 2 x 6 | 2×84/ 0,30 | 0,8 | 5.2 | 0,006 | 3,30 |
Product Show :
We are China Hot Sale PVC 4mm CCA Wire Twisted Pair Wire Red and White Rvs Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
