Free Sample Electric Cable Wire 2c*0.75/1.0/1.5/2.5/4.0/6.0/10mm2 Bare Copper Wire Strand with Different Color Rvs Wire and Cable

Free Sample Electric Cable Wire 2c*0.75/1.0/1.5/2.5/4.0/6.0/10mm2 Bare Copper Wire Strand with Different Color Rvs Wire and Cable image

Get Latest Price Request a quote

Product Details

Model NO.

RVS

Conductor Material

Copper

Sheath Material

None

Insulation Material

PVC

Material Shape

Twisting

Range of Application

Lighting, Installation House Building

Certification

ISO9001, CE, SGS TUV

Brand

Ume

Third Party Inspection

Accepted

Sample

Free

Color

Customer Specified

OEM

Accepted

Printing

Laser Printing , Hot Printing , Ink Printing

Transport Package

Drum or Roll

Specification

RVS

Trademark

UME

Origin

China

HS Code

8544492100

Production Capacity

7000km Per Month

Product Description

ONE-STOP SOLUTIONS FOR WIRES&CABLES – HENAN UME CABLE CO., LTD
Over 30 years of Wires and Cables manufacture experience and Export to over 50 countries.

Model	RVV
Conductor material	Oxygen-free copper
Insulation material	PVC
Number of cores	2 cores
Color	Customer Specified

1. Applications
RVS wire is called copper-cored PVC insulated stranded connection use soft wire, pair twisted multi-stranded soft wire, referred to as twisted pair cable, commonly known as “flower wire” in China. At present, this kind of wire is mostly used in fire fighting system, also known as “fire lines”.

Twisted RVS Cable full name copper core PVC insulated stranded connection soft wire, twisted multi-strand soft wire, referred to as twisted pair, commonly known as “flower line”, at this stage, this kind of wire is mostly used in the fire protection system, also called “fire line”. The letter S stands for twisted pair The letter R stands for the cord The letter V stands for polyvinyl chloride (insulator)

2. Standards
RVS cable implements the standards GB/T5023, equivalent to IEC60 227. And it can also be made to comply with ASTM, DIN, BS standards, etc. In addition, we can design and manufacture the products as the requirements of customers.

3. Structure
1. Suitable to be installed in electrical power transmission and distribution lines rated voltage 450/750V.
2. conductor’s rated working temperature:≤70
3.Short-circuit temperature160/5sec
4. Cable laying environment≥0
5. Cable laying, bend radius≥10 times cable O.D.

4. Feature
1. Rvs cable is mostly used for the detector circuit of the fire alarm automatic alarm system.
2. Suitable for household appliances, small power tools, instrumentation, and power lighting. A double white core is used for direct connection to the lamp line; a red and blue core is used for fire protection, alarm, etc.; a red and white core is used for broadcasting and telephone lines; a red and black core is used for broadcasting lines.
3. Rvs cable is used to connect the amplifier and audio equipment, and the broadcast system transmits the audio signal amplified by the power amplifier.

RVS Parameter

Core No.×nominal sectional area	Single wire diameter(mm)	Insulation thickness (mm)	Outer diameter(mm)	20 ºCmaximum conductor resistance(Ω/km)		70 ºCinsulation minimum resistance(mΩ/km)
				Annealed copper	Tinned copper
2×0.5	0.16	0.8	6	39	40.1	0.016
2×0.75	0.16	0.8	6.2	26	26.7	0.014
2×1.0	0.16	0.8	6.6	19.5	20	0.011
2×1.5	0.16	0.8	7.2	13.3	13.7	0.01
2×2.5	0.16	0.8	8.2	7.98	8.21	0.009
2×4	0.16	0.8	9.2	4.95	5.09	0.007
2×6	0.21	1	10.6	3.3	3.39	0.006

UME CABLE has completed several third-party product certifications to ensure our customers that all of the wire and cable purchased and installed in your projects, will fully and consistently meet all criteria of the required production and performance standards, also you are guaranteed we (as the manufacturer) and the products supplied are both valid and continuously monitored by those globally recognized quality verification system listed as below: ISO9001, ISO14001, ISO45001, CE, SGS, TUV.

HENAN UME CABLE CO., LTD has a strict quality control policy in every step from the order to After-sales service!

Production:

Raw material inspection and test
Production process test
Unqualified product control
Regular test and examination
Finished product inspection

500 kV double-circuit transmission line – Pakistan
230 kV Lamphun 3-Chom Thong transmission line – Thailand
Supply of ACSR moose conductor – Nepal
230/66/11 kV Mawlamyine-Ye-Dawei transmission line – Myanmar
400 kV Khandukhal-Rampura double-circuit transmission line – India
Reconductoring 132 kV Kabirpur-Kaliakoir and Kaliakoir-Tangail double-circuit transmission lines – Bangladesh

UME CABLE is one of the leading companies in the production and distribution of cables and wires in China. As a manufacturer, we have supplied quality products to more than 50 countries. Our mission is to offer our customers the best quality cable and wire products at the most competitive price, to extend and zoom the business success of our partners, to make power reach where it is needed, to optimize the running utility grids, and ultimately, to power the world. Our version is to be the most customer-centric cable and wire company with our solid technology, enthusiastic services, and robust products.

UME CABLE was founded in 1994, located in Zhengzhou Gongyi Huiguo Town, and occupies a total area of more than 200,000 square meters, with a building area of 20,000 square meters. The real capital assets are more than USD 6 million, with a total of 230 staff members, 35 of which are professional and technical experts. The land of our factory and employees numbers might not be the top scale of industry, but our highly automatic facilities and elite employees are the best in the industry will guarantee you a high yield rate achieved by strict cost and quality control, this is why we could quote better quality with a most competitive price within the market.

Q1: Are you a manufacturer?
Yes, we are the manufacturer.

Q2: What are your main products?
Our products range as follows:
1. Electrical wire/PVC Building Wires.
2. PVC/XLPE insulated Power Cables up to 110kv.
3. Overhead Aerial Bundle Cable/ABC Cables.
4. Bare Conductors, like AAC, AAAC, ACSR, ACAR, ASCR/AW, and so on.
5. Steel wire/strand-like EHS, GSW and ACS(Aluminum Clad Steel), CCS(Copper Clad Steel).
6. Rubber Cables, Mining Cables, Welding Cable, and Control Cables.
7. Concentric Cables with Copper/Aluminum/Aluminum Alloy 8000s’ Conductor.

Q3: Do you provide samples? Is it free or extra?
Yes, we could offer the samples for free

Q4: Is the quality of your products guaranteed?
We have passed ISO9001, ISO14001, ISO45001, and all our products have CE certificates.

Q5: Which markets do you involve mainly in?
Our products have been exported mainly to Africa, the Middle East, Southeast Asia, South America, Central America, North America, Europe, Australia, etc.

Q6: What is your payment term?
T/T or L/C

Q7: What about the delivery time?
Generally, it is 3-7days if the goods are in stock. Or it is 7-30days if the goods are not in stock, it is according to quantity.

O.D

We are China Free Sample Electric Cable Wire 2c*0.75/1.0/1.5/2.5/4.0/6.0/10mm2 Bare Copper Wire Strand with Different Color Rvs Wire and Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
