Free Sample Bare Conductor All Aluminum Conductor AAC

Free Sample Bare Conductor All Aluminum Conductor AAC image

Get Latest Price Request a quote

Product Details

Model NO.

AAC Conductor

Conductor Material

Aluminum

Sheath Material

None

Insulation Material

Bare

Material Shape

Round Wire

Range of Application

Overhead

Certification

ISO9001, CE, SGS TUV

Brand

Ume

Third Party Inspection

Accepted

Sample

Free

Color

Customer Specified

OEM

Accepted

Transport Package

Drum

Specification

up to 3500MCM

Trademark

UME

Origin

China

HS Code

7614900000

Production Capacity

500, 000km Per Month

Product Description

ONE-STOP SOLUTIONS FOR WIRES&CABLES – HENAN UME CABLE CO., LTD
Over 30 years of Wires and Cables manufacture experience and Export to over 50 countries.

1. Applications
AAC is widely used in overhead transmission and distribution lines of various voltage levels, especially for capacity expansion of urban lines.

2. Construction
These aluminium conductors are made up of one or more aluminium wires strands depending on their usage, mainly used in urban areas for electricity transfer.

3. Standards
IEC 61089, DIN 48201-5, ASTM B231, BS 215 PART1

IEC 61089

Code Name	Nominal Area	No. & Dia. of Wire	Approx. Overall Dia.	Approx. Weight	Nominal Breaking Load	Max. DC Resistance at 20°C
Code Name	mm2	No./mm	mm	kg/km	kN	Ω/km
10	10.0	7/1.35	4.05	27.4	2.0	2.8633
16	16.0	7/1.71	5.13	43.8	3.0	1.7896
25	25.0	7/2.13	6.39	68.4	4.5	1.1453
40	40.0	7/2.70	8.10	109.4	6.8	0.7158
63	63.0	7/3.39	10.17	172.3	10.4	0.4545
100	100.0	19/2.59	12.95	274.8	17.0	0.2877
125	125.0	19/2.89	14.45	343.6	21.3	0.2302
160	160.0	19/3.27	16.35	439.8	26.4	0.1798
200	200.0	19/3.66	18.30	549.7	32.0	0.1439
250	250.0	19/4.09	20.45	687.1	40.0	0.1151
315	315.0	37/3.29	23.03	867.9	52.0	0.0916
400	400.0	37/3.71	25.97	1102.0	64.0	0.0721
450	450.0	37/3.94	27.58	1239.8	72.0	0.0641
500	500.0	37/4.15	29.05	1377.6	80.0	0.0577
560	560.0	37/4.39	30.73	1542.9	89.6	0.0515
630	630.0	61/3.63	32.67	1738.3	100.8	0.0458
710	710.0	61/3.85	34.65	1959.1	113.6	0.0407
800	800.0	61/4.09	36.81	2207.4	128.0	0.0361
900	900.0	61/4.33	38.97	2483.3	144.0	0.0321
1000	1000.0	61/4.57	41.13	2759.2	160.0	0.0289
1120	1120.0	91/3.96	43.56	3093.5	179.2	0.0258
1250	1250.0	91/4.18	45.98	3452.6	200.0	0.0231
1400	1400.0	91/4.43	48.73	3866.9	224.0	0.0207
1500	1500.0	91/4.58	50.38	4143.1	240.0	0.0193

DIN 48201-5

Area		No. & Dia. of Wire	Approx. Overall Dia.	Approx. Weight	Nominal Breaking Load	Max. DC Resistance at 20°C
Nominal	Actual	No. & Dia. of Wire	Approx. Overall Dia.	Approx. Weight	Nominal Breaking Load	Max. DC Resistance at 20°C
mm2	mm2	No./mm	mm	kg/km	kN	Ω/km
16	15.9	7/1.70	5.10	43.0	2.8	1.8022
25	24.3	7/2.10	6.30	66.0	4.2	1.1810
35	34.4	7/2.50	7.50	94.0	5.8	0.8333
50	49.5	7/3.00	9.00	135.0	7.9	0.5787
50	48.4	19/1.80	9.00	133.0	8.5	0.5951
70	65.8	19/2.10	10.50	181.0	11.3	0.4372
95	93.3	19/2.50	12.50	256.0	15.7	0.3085
120	117.0	19/2.80	14.00	322.0	18.8	0.2459
150	147.1	37/2.25	15.80	406.0	25.3	0.1960
185	181.6	37/2.50	17.50	500.0	30.5	0.1588
240	242.5	61/2.25	20.30	670.0	39.5	0.1191
300	299.4	61/2.50	22.50	827.0	47.7	0.0965
400	400.1	61/2.89	26.00	1104.0	60.9	0.0722
500	499.8	61/3.23	29.10	1379.0	74.7	0.0578
625	626.2	91/2.96	32.60	1732.0	95.3	0.0462
800	802.1	91/3.35	36.90	2218.0	118.4	0.0360
1000	999.7	91/3.74	41.10	2767.0	145.8	0.0289

ASTM B231

Code Name	Nominal Area		No./ Dia. of Wire	Approx. Overall Dia.	Approx. Weight	Nominal Breaking Load	Max. DC Resistance at 20°C
Code Name	AWG or MCM	mm2	No./mm	mm	kg/km	kN	Ω/km
Peachbell	6	13.3	7/1.56	4.68	36.6	2.5	2.1477
Rose	4	21.1	7/1.96	5.88	58.2	3.9	1.3606
Iris	2	33.6	7/2.47	7.41	92.6	6.0	0.8567
Pansy	1	42.4	7/2.78	8.34	116.6	7.3	0.6763
Poppy	1/0.0	53.5	7/3.12	9.36	147.2	8.8	0.5369
Aster	2/0.0	67.4	7/3.50	10.50	185.7	11.1	0.4267
Phlox	3/0.0	85.0	7/3.93	11.79	233.9	13.5	0.3384
Oxlip	4/0.0	107.2	7/4.42	13.26	295.2	17.0	0.2675
Valerian	250.0	126.7	19/2.91	14.55	348.6	20.7	0.2274
Sneezewort	250.0	126.7	7/4.80	14.40	348.8	20.1	0.2269
Laurel	266.8	135.2	19/3.01	15.05	372.2	22.1	0.2125
Daisy	266.8	135.2	7/4.96	14.88	372.3	21.4	0.2125
Peony	300.0	152.0	19/3.19	15.95	418.3	24.3	0.1892
Tulip	336.4	170.5	19/3.38	16.90	469.5	27.3	0.1686
Daffodil	350.0	177.3	19/3.45	17.25	487.9	28.4	0.1618
Canna	397.5	201.4	19/3.67	18.35	554.9	31.6	0.1430
Goldentuft	450.0	228.0	19/3.91	19.55	627.6	35.0	0.1260
Syringa	477.0	241.7	37/2.88	20.16	664.8	38.6	0.1192
Cosmos	477.0	241.7	19/4.02	20.10	664.8	37.0	0.1192
Hyacinth	500.0	253.3	37/2.95	20.65	696.8	40.5	0.1136
Zinnia	500.0	253.3	19/4.12	20.60	697.1	38.9	0.1134
Dahlia	556.5	282.0	19/4.35	21.75	775.8	43.3	0.1018
Mistletoe	556.5	282.0	37/3.12	21.84	775.7	44.3	0.1016
Meadowsweet	600.0	304.0	37/3.23	22.61	836.3	47.5	0.0948
Orchid	636.0	322.3	37/3.33	23.31	886.9	50.4	0.0892
Heuchera	650.0	329.4	37/3.37	23.59	907.4	51.7	0.0871
Flag	700.0	354.7	61/2.72	24.48	975.8	57.1	0.0811
Varbena	700.0	354.7	37/3.49	24.43	975.7	55.4	0.0812
Nasturtium	715.5	362.6	61/2.75	24.75	998.5	58.4	0.0793
Violet	715.5	362.6	37/3.53	24.71	998.5	56.7	0.0794
Cattail	750.0	380.0	61/2.82	25.38	1046.0	60.3	0.0754
Petunia	750.0	380.0	37/3.62	25.34	1046.0	58.6	0.0755
Lilac	795.0	402.8	61/2.90	26.10	1110.0	63.8	0.0713
Arbutus	795.0	402.8	37/3.72	26.04	1109.0	61.8	0.0715
Snapdragon	900.0	456.0	61/3.09	27.81	1256.0	70.8	0.0628
Cockscomb	900.0	456.0	37/3.96	27.72	1256.0	68.4	0.0631
Goldenrod	954.0	483.4	61/3.18	28.62	1331.0	75.0	0.0593
Magnolia	954.0	483.4	37/4.08	28.56	1331.0	72.6	0.0594
Camellia	1000.0	506.7	61/3.25	29.25	1394.0	78.3	0.0568
Hawkweed	1000.0	506.7	37/4.18	29.26	1395.0	76.2	0.0566
Larkspur	1033.5	523.7	61/3.31	29.79	1442.0	81.3	0.0547
Bluebell	1033.5	523.7	37/4.25	29.75	1441.0	78.8	0.0547
Marigold	1113.0	564.0	61/3.43	30.87	1553.0	87.3	0.0510
Hawthorn	1192.5	604.2	61/3.55	31.95	1662.0	93.5	0.0476
Narsissus	1272.0	644.5	61/3.67	33.03	1774.0	98.1	0.0445
Columbine	1351.0	694.8	61/3.78	34.02	1884.0	104.0	0.0420
Carnation	1431.0	725.1	61/3.89	35.01	1997.0	108.0	0.0396
Gladiolus	1510.5	765.4	61/4.00	36.00	2108.0	114.0	0.0375
Coreopsis	1590.0	805.7	61/4.10	36.90	2216.0	120.0	0.0357
Jassamine	1750.0	886.7	61/4.30	38.70	2442.0	132.0	0.0324
Cowslip	2000.0	1013.0	91/3.77	41.47	2787.0	153.0	0.0286
Sagebrush	2250.0	1140.0	91/3.99	43.89	3166.0	167.0	0.0255
Lupine	2500.0	1267.0	91/4.21	46.31	3519.0	186.0	0.0229
Bitterrot	2750.0	1393.0	91/4.42	48.62	3872.0	205.0	0.0208
Trillium	3000.0	1520.0	127/3.90	50.70	4226.0	223.0	0.0193
Bluebonnet	3500.0	1773.0	127/4.22	54.86	4977.0	261.0	0.0165

BS 251-1

Code Name	Nominal Area	No.& Dia. of Wire	Approx. Overall Dia.	Total Area	Approx. Weight	Nominal Breaking Load	Max. DC Resistance at 20°C
Code Name	mm2	No./mm	mm	mm2	kg/km	kN	Ω/km
Midge	22.0	7/2.06	6.18	23.3	64.0	4.0	1.2270
Ant	50.0	7/3.10	9.30	52.8	145.0	8.3	0.5419
Fly	60.0	7/3.40	10.20	63.6	174.0	9.9	0.4505
Wasp	100.0	7/4.39	13.17	106.0	290.0	16.0	0.2702
Hornet	150.0	19/3.25	16.25	157.6	434.0	25.7	0.1825
Chafer	200.0	19/3.78	18.90	213.2	587.0	32.4	0.1349
Cockroach	250.0	19/4.22	21.10	265.7	731.0	40.4	0.1083
Butterfly	300.0	19/4.65	23.25	322.7	888.0	48.8	0.0892
Centipede	400.0	37/3.78	26.46	415.2	1145.0	63.1	0.0694

HENAN UME CABLE CO., LTD has a strict quality control policy in every step from the order to After-sales service!

Production:

Raw material inspection and test
Production process test
Unqualified product control
Regular test and examination
Finished product inspection

UME CABLE has completed several third-party product certifications to ensure our customers that all of the wire and cable purchased and installed in your projects, will fully and consistently meet all criteria of the required production and performance standards, also you are guaranteed we (as the manufacturer) and the products supplied are both valid and continuously monitored by those globally recognized quality verification system listed as below: ISO9001, ISO14001, ISO45001, CE, SGS, TUV.

UME CABLE is one of the leading companies in the production and distribution of cables and wires in China. As a manufacturer, we have supplied quality products to more than 50 countries. Our mission is to offer our customers the best quality cable and wire products at the most competitive price, to extend and zoom the business success of our partners, to make power reach where it is needed, to optimize the running utility grids, and ultimately, to power the world. Our version is to be the most customer-centric cable and wire company with our solid technology, enthusiastic services, and robust products.

UME Cable was founded in 1994, located in Zhengzhou Gongyi Huiguo Town, and occupies a total area of more than 200,000 square meters, with a building area of 20,000 square meters. The real capital assets are more than USD 6 million, with a total of 230 staff members, 35 of which are professional and technical experts. The land of our factory and employees numbers might not be the top scale of industry, but our highly automatic facilities and elite employees are the best in the industry will guarantee you a high yield rate achieved by strict cost and quality control, this is why we could quote better quality with the most competitive price within the market.

Q1: Are you a manufacturer?
Yes, we are the manufacturer.

Q2: What are your main products?
Our products range as follows:
1. Electrical wire/PVC Building Wires.
2. PVC/XLPE insulated Power Cables up to 110kv.
3. Overhead Aerial Bundle Cable/ABC Cables.
4. Bare Conductors, like AAC, AAAC, ACSR, ACAR, ASCR/AW, and so on.
5. Steel wire/strand-like EHS, GSW and ACS(Aluminum Clad Steel), CCS(Copper Clad Steel).
6. Rubber Cables, Mining Cables, Welding Cable, and Control Cables.
7. Concentric Cables with Copper/Aluminum/Aluminum Alloy 8000s’ Conductor.

Q3: Do you provide samples? Is it free or extra?
Yes, we could offer the samples for free

Q4: Is the quality of your products guaranteed?
We have passed ISO9001, ISO14001, ISO45001, and all our products have CE certificates.

Q5: Which markets do you involve mainly in?
Our products have been exported mainly to Africa, the Middle East, Southeast Asia, South America, Central America, North America, Europe, Australia, etc.

Q6: What is your payment term?
T/T or L/C

Q7: What about the delivery time?
Generally, it is 3-7days if the goods are in stock. Or it is 7-30days if the goods are not in stock, it is according to quantity.
