Electric Armoured Cable High Voltage 4 Core Armored Cu/XLPE/Swa/PVC Underground Cable

Electric Armoured Cable High Voltage 4 Core Armored Cu/XLPE/Swa/PVC Underground Cable image

Get Latest Price Request a quote

Product Details

Model NO.

YJV

Current

AC Cable

Insulation Material

PVC

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE, RoHS, VDE

Name

PVC Power Cable

Market

Global

Hot Sale Size

70mm, 120mm,400mm,95mm

Other Core

1 Core, 2 Core, 3 Core, 4 Core, 5 Core

Type

Low Voltage

Transport Package

Wooden Drum

Specification

4x50mm2

Trademark

QINSHAN

Origin

China

HS Code

8544492100

Production Capacity

8000000meters/Month

Product Description

electric armoured cable High voltage 4 core armored cu/xlpe/swa/pvc underground electrical cable pvc cable oem

Construction :

Conductor: Solid & stranded copper wire class1&2 acc.to IEC60228

Solid & stranded Aluminium wire

Insulation:PVC Compound
Filler: PVC Compound
Sheath:PVC Compound
Sheath Color:White ,Black,Grey

Techical Data :

Standard:IEC 60502-1 / VDE 0276 /NT88-22
Fixed installed: -15ºC up to 70ºC
At short circuit of max.5s up to 160ºC
Nominal Voltage : 600/1000V

Min inner bending radius:
Single coe:15D
Multi core:12D
Behaviour in fire:
Flame retardant cable acc.to IEC60332-1

Application:

PVC power cable for static outdoor application (with protection against direct UV-irradiation), in ground, in water, within facilities, in cable canals, in concrete, in conditions where heavier mechanical loads and specially tensile strains, are not expected. Used in electric power plants, transformer stations, industrial plants, metropolitan networks and in other electric plants, same as for connection of signalling devices in industry, traffic and similar.

Technical Parameters:

No.of cores x Nominal section area	Nominal Construction of conductor	Nominal Insulation thickness	Nominal Sheath thickness	Nominal Overall diameter	Nominal Cable weight	Max.Resistance of conductor at 20ºC
No.X mm²	No.X mm	mm	mm	mm	kg/km	<=(Ω/km)
Three core PVC Power Cables CU/XLPE/PVC( AL/XLPE/PVC )
3×1.5	2x 1.38	0,7	1,8	11.3	130	12,10
3×2.5	7 x 0,67	0,7	1,8	11.8	170	7,41
3×4.0	7 x 0,85	0,7	1,8	13.1	230	4,61
3×6.0	7 x 1,04	0,7	1,8	13.9	305	3,08
3×10	7 x 1,35	0,7	1,8	17.5	450	1,83
3×16	7 x 1,70	0,7	1,8	18.2	615	1,150
3×25	7 x 2,14	0,9	1,8	19.1	870	0,727
3×35	7 x 2,52	0,9	1,8	21.1	1155	0,524
3×50	19 x 1,78	1,0	1,8	23.8	1530	0,387

No.of cores x Nominal section area	Nominal Construction of conductor	Nominal Insulation thickness	Nominal Sheath thickness	Nominal Overall diameter	Nominal Cable weight	Max.Resistance of conductor at 20ºC
No.X mm²	No.X mm	mm	mm	mm	kg/km	<=(Ω/km)
Four core PVC Power Cables CU/XLPE/PVC( AL/XLPE/PVC )
4×1.5	2x 1.38	0,7	1,8	12.1	150	12,10
4×2.5	7 x 0,67	0,7	1,8	13.2	200	7,41
4×4.0	7 x 0,85	0,7	1,8	14.9	275	4,61
4×6.0	7 x 1,04	0,7	1,8	16.1	370	3,08
4×10	7 x 1,35	0,7	1,8	18.6	560	1,83
4×16	7 x 1,70	0,7	1,8	20.2	795	1,150
4×25	7 x 2,14	0,9	1,8	21.8	1130	0,727
4×35	7 x 2,52	0,9	1,8	24.1	1515	0,524
4×50	19 x 1,78	1,0	1,9	27.5	2010	0,387
4×70	19 x 2,14	1,1	2,0	31.7	2860	0,268
4×95	19 x 2,52	1,1	2,1	35.4	3870	0,193
4×120	37 x 2,03	1,2	2,3	39.2	4850	0,153
4×150	37 x 2,25	1,4	2,4	43.8	5980	0,124
4×185	37 x 2,52	1,6	2,6	48.7	7480	0,0991
4×240	61 x 2,25	1,7	2,8	54.4	9735	0,0754
4×300	61 x 2,52	1,8	3,0	59.9	12120	0,0601

Product Show:

Power cables is used in power transmission and distribution line.It does not only have excellent electric, mechanical properties,but also has powerfulresistance against chemical corrosion, heat aging and environmental stress.

Features:
Conductor: creep resistance, high flexibility, strong extended, low rebound, connection stability.
Insulation: high temperature resistant, anti-burning, anti-aging, strong and durable, low-carbon environment.
Armored layer: Lower cost and better performance, a special form of interlocking, sturdy and tough.
Outer sheath:without lead, cadmium in PVC, can be installed in wet or damp locations, can also be directly buried or laid in the construction.

We are China Electric Armoured Cable High Voltage 4 Core Armored Cu/XLPE/Swa/PVC Underground Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
