Copper Electric Building Wire for Building Wire
copper electric building wire is included the followings:
electric building wire are mainly complying with iec 60502 standard, also can be produced according to OEM requirements and other standards, such as bs standard, din standard, ASTM standard, etc.
electric building wire Laying conditions: For lyaing under ground with large different altitude, be able to bear external machanical force and moderate pulling force.
Conductor:
Solid or stranded Aluminum&cooper
copper electric building wire Include following code and specification
| Normal Cross Sectional Area of Conductor (mm2 ) |
Normal Diameter of Strand (mm) |
Normal Thickness of Insulation (mm) |
Normal Thickness of Jacket (mm) |
Over Diameter of Cable (mm) |
Max Conductor Resistance at 20°C ( ≤Ω/km ) |
| 2×0.75 | 0.20 | 0.6 | 0.8 | 6.1~7.0 | 26.0 |
| 2×1 | 0.20 | 0.6 | 0.9 | 6.6~7.3 | 19.5 |
| 2×1.5 | 0.25 | 0.8 | 1.0 | 8.1~9.1 | 13.3 |
| 2×2.5 | 0.25 | 0.9 | 1.1 | 9.7~11.0 | 7.98 |
| 3×0.75 | 0.20 | 0.6 | 0.9 | 6.7~7.6 | 26.0 |
| 3×1 | 0.20 | 0.6 | 0.9 | 7.0~7.9 | 19.5 |
| 3×1.5 | 0.25 | 0.8 | 1.0 | 8.6~9.6 | 0.268 |
| 3×2.5 | 0.25 | 0.9 | 2.0 | 10.1~11.8 | 0.198 |
| 4×0.75 | 0.20 | 0.6 | 2.0 | 7.3~8.2 | 0.161 |
| 4×1 | 0.20 | 0.6 | 0.9 | 7.6~8.5 | 19.5 |
| 4×1.5 | 0.25 | 0.8 | 1.1 | 9.6~10.9 | 13.3 |
| 4×2.5 | 0.25 | 0.9 | 1.2 | 11.5~13.2 | 7.98 |
| 5×0.75 | 0.20 | 0.6 | 1.0 | 8.1~9.1 | 26.0 |
| 5×1 | 0.20 | 0.6 | 1.0 | 8.5~9.5 | 19.5 |
| 5×1.5 | 0.25 | 0.8 | 1.1 | 10.5~12.0 | 13.3 |
| 5×2.5 | 0.25 | 0.9 | 1.3 | 12.8~14.7 | 7.98 |
Company Information
We are China Copper Electric Building Wire for Building Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
