AAC (All Aluminum Conductor)
AAC(All aluminum conductor) are suited for overhead power line.
We can supply this conductor according to different recognized standards, such as IEC61089, BS215, ASTM B231, CSA C49, DIN480201, JIS C3109, customer special specification also can be satisfied.
The data sheets below show the standards IEC61089:
| Code Number | Nominal area | Stranding& | Approx | Approx | Breaking load | DC Resistance at 20 |
| Wire | overall | weight | ||||
| Diameter | diameter | |||||
| mm 2 | mm | mm | Kg/km | KN | Ohm/km | |
| 10 | 10 | 7/1.35 | 4.05 | 27.4 | 1.95 | 2.8633 |
| 16 | 16 | 7/1.71 | 5.12 | 43.8 | 3.04 | 1.7896 |
| 25 | 25 | 7/2.13 | 6.4 | 68.4 | 4.5 | 1.1453 |
| 40 | 40 | 7/2.70 | 8.09 | 109.4 | 6.8 | 0.7158 |
| 63 | 63 | 7/3.39 | 10.2 | 172.3 | 10.39 | 0.4545 |
| 100 | 100 | 19/2.59 | 12.9 | 274.8 | 17 | 0.2877 |
| 125 | 125 | 19/2.89 | 14.5 | 343.8 | 21.25 | 0.2302 |
| 160 | 160 | 19/3.27 | 16.4 | 439.8 | 26.4 | 0.1798 |
| 200 | 200 | 19/3.66 | 18.3 | 549.7 | 32 | 0.1439 |
| 250 | 250 | 19/4.09 | 20.5 | 687.1 | 40 | 0.1151 |
| 400 | 400 | 37/3.71 | 26 | 1102 | 64 | 0.0721 |
| 450 | 450 | 37/3.94 | 27.5 | 1239.8 | 72 | 0.0641 |
| 500 | 500 | 37/4.15 | 29 | 1377.6 | 80 | 0.0577 |
| 560 | 560 | 37/4.39 | 30.7 | 1542.9 | 89.6 | 0.0515 |
| 630 | 630 | 61/3.63 | 32.6 | 1738.3 | 100.8 | 0.0458 |
| 710 | 710 | 61/3.85 | 34.6 | 1959.1 | 113.6 | 0.0407 |
| 800 | 800 | 61/4.09 | 36.8 | 2207.4 | 128 | 0.0361 |
| 900 | 900 | 61/4.33 | 39 | 2483.3 | 144 | 0.0321 |
| 1000 | 1000 | 61/4.57 | 41.1 | 2759.2 | 160 | 0.0289 |
| 1120 | 1120 | 91/3.96 | 43.5 | 3093.5 | 179.2 | 0.0258 |
| 1250 | 1250 | 91/4.18 | 46 | 3452.6 | 200 | 0.0231 |
| 1400 | 1400 | 91/4.43 | 48.7 | 3866.9 | 224 | 0.0207 |
| 1500 | 1500 | 91/4.58 | 50.4 | 4143.1 | 240 | 0.0193 |
