336.4mcm ACSR Merlin Bare Aluminum Conductors Steel Reinforced Manufacturing Cable China

336.4mcm ACSR Merlin Bare Aluminum Conductors Steel Reinforced Manufacturing Cable China image

Get Latest Price Request a quote

Product Details

Model NO.

Bare conductor, ACSR conductor cable

Conductor Material

Aluminum

Sheath Material

Bare

Insulation Material

Bare

Material Shape

Round Wire

Range of Application

Overhead Power Transmission Supply

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Kingyear

Standard

BS 215, ASTM B232, DIN 48204

Delivery

7-25days After Received The Prepayment

Hot Sale Countries

Philippine, Yemen, Vietnam, Indonesia

Transport Package

Wooden Drum or Roll, Iron Drum

Specification

10mm2-1500mm2

Trademark

KINGYEAR

Origin

Henan, China

HS Code

7614100000

Production Capacity

500km/Month

Product Description

336.4mcm Acsr Merlin Bare Aluminum Conductors Steel Reinforced Manufacturing Cable China

Applications:
ACSR conductors are formed by several wires of aluminium and galvanized steel, stranded in concentric layers. The wire or wires which form the core, are made of galvanized steel and the external layer or layers, are of aluminium. Galvanized steel core consist normally of 1, 7 or 19 wires. Aluminum 1350 wires and the steel cores are concentrically stranded and wrapped helically around a central wire. The additional corrosion protection is available through the application of grease to the cores or infusion of the complete cable with grease.

Standard
IEC61089, BS 215, ASTM B232, CSA C49, DIN48204, JIS C3110

The technical data of ACSR(Aluminum Conductor Steel Reinforced) Bare Conductor Cable as below for reference,any customized is available.

ASTM B 232
ASTM B 232
Code Name	Size	No./Dia.of Stranding Wires		Approx. Overall Dia.	Approx. Weight
	AWG or MGM	Alum.	ST.	Approx. Overall Dia.	Approx. Weight
	AWG or MGM	No./mm	No./mm	mm	kg/km
Swanate	4	7/1.96	1/2.61	6.53	93
Sparrow	2	6/2.67	1/2.67	8.01	129
Sparate	2	7/2.47	1/3.30	8.24	148
Robin	1	6/3.00	1/3.00	9	163
Raven	1/0	6/3.37	1/3.37	10.11	206
Quail	2/0	6/3.78	1/3.78	11.34	259
Pigeon	3/0	6/4.25	1/4.25	12.75	327
Penguin	4/0	6/4.77	1/4.77	14.31	412
Waxwing	266.8	18/3.09	1/3.09	15.45	422
Merlin	336.4	18/3.47	1/3.47	17.35	532
Linnet	336.4	26/2.89	7/2.25	18.31	656
Oriole	336.4	30/2.69	7/2.69	18.83	737
Chickadee	397.5	18/3.77	1/3.77	18.85	629
Ibis	397.5	26/3.14	7/2.44	19.88	775
Lark	397.5	30/2.92	7/2.92	20.44	871
Pelican	477	18/4.14	1/4.14	20.7	754
Flicker	477	24/3.58	7/2.39	21.49	877
Hawk	477	26/3.44	7/2.67	21.8	931
Hen	477	30/3.20	7/3.20	22.4	1044
Osprey	556.5	18/4.47	1/4.47	22.35	880
Parakeet	556.5	24/3.87	7/2.58	23.22	1023
Dove	556.5	26/3.72	7/2.89	23.55	1085
Eagle	556.5	30/3.46	7/3.46	24.21	1219
Peacock	605	24/4.03	7/2.69	24.2	1112
Squab	605	26/3.87	7/3.01	24.51	1180
WoodDuck	605	30/3.61	7/3.61	25.25	1325
Kingbird	636	18/4.78	1/4.78	23.88	1007
Rook	636	24/4.14	7/2.76	24.84	1170
Grosbeak	636	26/3.97	7/3.09	25.15	1240
Scoter	636	30/3.70	7/3.70	25.88	1393
Swift	636	36/3.38	1/3.38	23.62	947
Flamingo	666.6	24/4.23	7/2.82	25.4	1226
Gannet	666.6	26/4.07	7/3.16	25.76	1300
Stilt	715.5	24/4.39	7/2.92	26.31	1316
Starling	715.5	26/4.21	7/3.28	26.68	1396
Redwing	715.5	30/3.92	19/2.35	27.43	1553
Tern	795	45/3.38	7/2.25	27.03	1300
Condor	795	54/3.08	7/3.08	27.72	1461
Cuckoo	795	24/4.62	7/3.08	27.74	1461
Drake	795	26/4.44	7/3.45	28.11	1550
Coot	795	36/3.77	1/3.77	26.41	1184
Mallard	795	30/4.14	19/2.48	28.96	1728
Ruddy	900	45/3.59	7/2.40	28.73	1472
Canary	900	54/3.28	7/3.28	29.52	1554
Rail	954	45/3.70	7/2.47	29.61	1560
Catbird	954	36/4.14	1/4.14	28.95	1421
Cardinal	954	54/3.38	7/3.38	30.42	1753
Ortlan	1033.5	45/3.85	7/2.57	30.81	1690
Tanager	1033.5	36/4.30	1/4.30	30.12	1539
Curlew	1033.5	54/3.52	7/3.52	31.66	1900
Bluejay	1113	45/4.00	7/2.66	31.86	1821
Bunting	1192.5	45/4.14	7/2.76	33.12	1949
Grackle	1192.5	54/3.77	19/2.27	33.97	2190
Bittern	1272	45/4.27	7/2.85	34.17	2080
Pheasant	1272	54/3.90	19/2.34	35.1	2335
Skylark	1272	36/4.78	1/4.78	33.42	1895
Dipper	1351.5	45/4.40	7/2.92	35.16	2210
Martin	1351.5	54/4.02	19/2.41	36.17	2481
Bobolink	1431	45/4.53	7/3.02	36.24	2342
Plover	1431	54/4.14	19/2.48	37.24	2628
Nuthatch	1510.5	45/4.65	7/3.10	37.2	2470
Parrot	1510.5	54/4.25	19/2.55	38.25	2773
Lapwing	1590	45/4.77	7/3.18	38.16	2599
High Strength Stranding
High Strength Stranding
Falcon	1590	54/4.36	19/2.62	39.26	2920
Grouse	80	8/2.54	1/4.242	9.32	204
Petrel	101.6	12/2.339	7/2.339	11.7	342
Minorca	110.8	12/2.441	7/2.441	12.2	373
Leghorn	134.6	12/2.69	7/2.69	13.45	453
Guinea	159	12/2.924	7/2.924	14.62	535
Dotterel	176.9	12/3.084	7/3.084	15.42	595
Dorking	190.8	12/3.203	7/3.203	16.01	642
Brahma	203.2	16/2.863	19/2.482	18.13	900
Cochin	211.3	12/3.371	7/3.371	16.85	711

ACSR BS 215
ACSR BS 215
Code Name	Calculated Area				Stranding and Wire Diameter.		Overall Diameter	Weight			Nominal Breaking Load	Max. D.C Resistance at 20 ºC
	Calculated Area				Stranding and Wire Diameter.			Weight
	Nominal Alum.	Alum.	Steel	Total	Alum.	Steel		Alum.	Steel.	Total
	Nominal Alum.	Alum.	Steel	Total	Alum.	Steel		Alum.	Steel.	Total
mm²	mm²	mm²	mm²	mm	mm	mm	mm	kg/km	kg/km	kg/km	kn	ohm/km
Mole	10	10.62	1.77	12.39	6/1.50	1/1.50	4.5	29	14	43	4.14	2.076
Squirrel	20	20.94	3.49	24.43	6/2.11	1/2.11	6.33	58	27	85	7.88	1.368
Gopher	25	26.25	4.37	30.62	6/2.36	1/2.36	7.08	72	34	106	9.61	1.093
Weasel	30	31.61	5.27	36.88	6/2.59	1/2.59	7.77	87	41	128	11.45	0.9077
Fox	35	36.66	6.11	42.77	6/2.79	1/2.79	8.37	101	48	149	13.2	0.7822
Ferret	40	42.41	7.07	49.48	6/3.00	1/3.00	9	117	55	172	15.2	0.6766
Rabbit	50	52.88	8.82	61.7	6/3.35	1/3.35	10.05	145	69	214	18.35	0.5426
Mink	60	63.18	10.53	73.71	6/3.66	1/3.66	10.98	173	82	255	21.8	0.4545
Skunk	60	63.27	36.93	100.3	12/2.59	7/2.59	12.95	175	290	465	53	0.4567
Beaver	70	74.82	12.47	87.29	6/3.99	1/3.99	11.97	205	97	302	25.7	0.3825
Horse	70	73.37	42.8	116.17	12/2.79	7/2.79	13.95	203	335	538	61.2	0.3936
Racoon	75	79.2	13.2	92.4	6/4.10	1/4.10	12.3	217	103	320	27.2	0.3622
Otter	80	83.88	13.98	97.86	6/4.22	1/4.22	12.66	230	109	339	28.8	0.3419
Cat	90	95.4	15.9	111.3	6/4.50	1/4.50	13.5	262	124	386	32.7	0.3007
Hare	100	105	17.5	122.5	6/4.72	1/4.72	14.16	288	137	425	36	0.2733
Dog	100	105	13.5	118.6	6/4.72	7/1.57	14.15	288	106	394	32.7	0.2733
Hyena	100	105.8	20.44	126.2	7/4.39	7/1.93	14.57	290	160	450	40.9	0.2712
Leopard	125	131.3	16.8	148.1	6/5.28	7/1.75	15.81	360	132	492	40.7	0.2184
Cougar	125	130.3	7.25	137.5	18/3.05	1/3.05	15.25	362	57	419	29.8	0.2189
Tiger	125	131.1	30.6	161.7	30/2.36	7/2.36	16.52	362	240	602	58	0.2202
Wolf	150	158	36.9	194.9	30/2.59	7/2.59	18.13	437	289	726	69.2	0.1828
Dingo	150	158.7	8.8	167.5	18/3.25	1/3.35	16.75	437	69	506	35.7	0.1815
Lynx	175	183.4	42.8	226.2	30/2.79	7/2.79	19.53	507	335	842	79.8	0.1576
Caracal	175	184.2	10.3	194.5	18/3.61	1/3.61	18.05	507	80	587	41.1	0.1563
Lion	225	238.3	55.6	294.2	30/3.18	7/3.18	22.26	659	436	1095	109.6	0.1212
Bear	250	264	61.6	325.6	30/3.35	7/3.55	23.45	730	483	1213	111.1	0.1093
Goat	300	324.3	75.7	400	30/3.71	7/3.71	25.97	896	593	1489	135.7	0.08911
Sheep	350	374.1	87.3	461.4	30/3.99	7/3.99	27.93	1034	684	1718	155.9	0.07704
Antelope	350	373.1	48.4	421.5	54/2.97	7/2.97	26.73	1032	379	1411	118.2	0.07727
Bison	350	381.8	49.5	431.3	54/3.00	7/3.00	27	1056	388	1444	120.9	0.07573
Jaguar	200	210.6	11.7	222.3	18/3.86	1/3.86	19.3	580	91	671	46.55	0.1367
Deer	400	429.3	100.2	529.5	30/4.27	7/4.27	29.89	1186	785	1971	178.5	0.06726
Zebra	400	428.9	55.6	484.5	54/3.18	7/3.18	28.62	1186	435	1621	131.9	0.0674
Elk	450	477	111.3	588.3	30/4.50	7/4.50	31.5	1318	872	2190	198.2	0.06056
Camel	450	475.2	61.6	536.8	54/3.35	7/3.35	30.15	1314	483	1797	145.7	0.06073
Moose	500	528.7	68.5	597.2	54/3.53	7/3.53	31.77	1462	537	1999	161.1	0.0547

FAQ
Q:I didn’t find the ACSR Bare Conductor Cable which I need in this page?

A:If you didn’t find the species of cables you need, please contact us directly, we will reply you quickly.

Q:What’s your minimum order quantity?
A:It is not so sure, you can confirm it with us. Normally, it will be 1000 meters.

Q:What’s your delivery time?
A:It depends on whether we just has the stock for your type.Normally,it takes about 7-15days to achieve production.

Q:How can I get a sample from your company? Is the sample free?
A:If you need the sample to check the quality, please contact us, we will send you the free sample, but the freight charge should be paid.

Q:How to ensure quality ?
A:For any quality problems, we will arrange the technical personnel to solve or return the goods as soon as possible, and bear the corresponding customer losses.

Q:What if the cable which we need have some differences on specifications from yours?
A: Any difference, we can design and produce according to your requests, which include cable, color, material, processing requirement etc.

As a leading manufacture in China,Our customers come from around the world,Welcome to visit us at any time!
Just leave your message if you are interested in our products,We will contact you very soon!

—————————————————–

—————————————————–

We are China 336.4mcm ACSR Merlin Bare Aluminum Conductors Steel Reinforced Manufacturing Cable China manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
